- Model NO.:MV-90
- Wire Core Material:Bare Copper Wire
- Certification:ISO, CCC
- Model:Mv-90
- Brand:Boan
- Rated Voltage:15 Kv
- Number of Cores:1
- Section:2 AWG-1000 Mcm
- Class of Conductor:B
- Insulation Level:100% or 133%
- Transport Package:Heated Steel-Wooden Drum,Steel Drum
- Specification:SGS
- Trademark:DingAn
- Origin:Jiangsu Yixing, China
- HS Code:8544601200
- Production Capacity:12000 Km,Year
100% Insulation Levels (175 mil) | 133% Insulation Levels (220 mil) |
Size | Number of Strands | Conductor Nominal | Diameter Over Insulation | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight | Diameter Over Insulation | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight |
Copper | Aluminum | Copper | Aluminum |
AWG of kcmil | | in | in | mil | in | lb/kft | in | mil | in | lb/kft |
2 | 7 | 0.27 | 0.65 | 80 | 0.94 | 524 | 382 | 0.74 | 80 | 1.03 | 583 | 441 |
1 | 19 | 0.3 | 0.68 | 80 | 0.97 | 591 | 412 | 0.77 | 80 | 1.06 | 652 | 472 |
1/0 | 19 | 0.34 | 0.72 | 80 | 1.01 | 677 | 450 | 0.81 | 80 | 1.10 | 740 | 513 |
2/0 | 19 | 0.38 | 0.76 | 80 | 1.05 | 781 | 495 | 0.85 | 80 | 1.14 | 847 | 561 |
3/0 | 19 | 0.42 | 0.81 | 80 | 1.10 | 912 | 551 | 0.90 | 80 | 1.19 | 980 | 619 |
4/0 | 19 | 0.48 | 0.86 | 80 | 1.15 | 1073 | 618 | 0.95 | 80 | 1.24 | 1144 | 689 |
250 | 37 | 0.52 | 0.92 | 80 | 1.2 | 1226 | 689 | 1.01 | 80 | 1.32 | 1323 | 785 |
300 | 37 | 0.57 | 0.97 | 80 | 1.25 | 1405 | 760 | 1.06 | 80 | 1.37 | 1505 | 861 |
350 | 37 | 0.62 | 1.01 | 80 | 1.32 | 1606 | 852 | 1.10 | 80 | 1.41 | 1687 | 933 |
400 | 37 | 0.66 | 1.05 | 80 | 1.37 | 1782 | 922 | 1.14 | 80 | 1.46 | 1865 | 1005 |
500 | 37 | 0.74 | 1.13 | 80 | 1.44 | 2130 | 1055 | 1.22 | 80 | 1.53 | 2218 | 1142 |
600 | 61 | 0.81 | 1.22 | 80 | 1.53 | 2491 | 1201 | 1.31 | 80 | 1.62 | 2584 | 1293 |
750 | 61 | 0.91 | 1.31 | 80 | 1.62 | 3003 | 1390 | 1.40 | 110 | 1.78 | 3205 | 1592 |
1000 | 61 | 1.06 | 1.47 | 110 | 1.84 | 3960 | 1810 | 1.56 | 110 | 1.96 | 4118 | 1968 |
