• Model NO.：GYFXBY-12B1
• Certification：CE
• Brand：OEM
• Sheath Material：PE
• Apply for：Aerial
• Fiber Count：1,2,4,6,8 as Per Your Design
• Cable Type：Sm or Mm
• Fiber Type：9,125 (G657A2)
• Material of Jacket：MDPE,HDPE
• Fiber Optic Cable Tube：Central Loose Tube
• Model Name：Fiber Optic Cable
• Model No.：Gjyxfch-8b6.A2
• Delivery Time：10 Days
• MOQ：2 Drum
• Transport Package：4km Wooden Drum
• Specification：GYFXBY-12B1
• Trademark：SOFTEL
• Origin：China
• HS Code：85176229
• Production Capacity：1000km Per Month

Basic Info.

Model NO. GYFXBY-12B1 Certification CE Brand OEM Sheath Material PE Apply for Aerial Fiber Count 1,2,4,6,8 as Per Your Design Cable Type Sm or Mm Fiber Type 9/125 (G657A2) Material of Jacket MDPE/HDPE Fiber Optic Cable Tube Central Loose Tube Model Name Fiber Optic Cable Model No. Gjyxfch-8b6.A2 Delivery Time 10 Days MOQ 2 Drum Transport Package 4km Wooden Drum Specification GYFXBY-12B1 Trademark SOFTEL Origin China HS Code 85176229 Production Capacity 1000km Per Month

Product Description

Self-supporting fiber optical drop cable 8 cores

1. Good mechanical and environmental characteristics;
2. Flame retardant characteristics meets the requirements of relevant standards;
3. The mechanical characteristics meets the requirements of relevant standards;
4. Soft, flexible, easy to splice, and with big capacity data transmission;
5. Meet various requirements of market and clients.

Characteristic:


1 Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.

2 Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber.

3 Single steel wire as the additional strength member ensure good performance of tensile strength.

4 Simple structure, light weight and high practicability.

5 Novel flute design, easily strip and splice, simplify the installation and maintenance.

6 Low smoke, zero halogen and flame retardant sheath.


Item	Technology parameter
Cable type	GYFXBY-12B1
Fiber type	9/125 (G652D)
Fiber color	Blue, orange, green, brown, gray, white, red, black, yellow, violet, pink, aqua
Filler	Jelly
Inner jacket color	Natural
Inner jacket material	PBT
Inner jacket diameter mm	3.0±0.1
Strength member	FRP(*2)
Strength member diameter mm	1.6
Outer sheath color	Black
Outer sheath material	PE
Outer sheath dimension mm	7.7(±0.3)×4.3(±0.3)
Cable weight Kg/km	Approx. 34.9
Min. bending radius mm	20H (Static)40H (Dynamic)
Attenuation dB/km	<= 0.4 at 1310nm, <= 0.3 at 1550nm
Short tensile strength N	800
Crush resistance N/100mm	2200
Operation temperature ºC	-20~+70
