• Model NO.：RG6
• Wire Core Material：Steel
• Certification：CE
• Model：RG6
• Brand：Softel
• Center Conductor：Bc,CCS
• Dielectric：0.18(4.57mm)Foam PE
• Shield：Bonded Al Foil 0.0016(0.04mm)
• Jacket：PVC
• Jelly/ADP：Per Customer Special Require
• Sparker Test：4000VAC
• Impedance：75 +,- 3 Ohm
• Capacitance：50+3PF,M
• Velocity of Propagation：85%
• Transport Package：Standard Paper Box
• Specification：100*100*90
• Trademark：Softel
• Origin：China
• HS Code：85176229
• Production Capacity：500 Box Per Week

ITEM

RG6S

RG6SM

RG6T(M)

RG6Q(M)

Center conductor

1.02mm + 0.01mm

1.02mm + 0.01mm

1.02mm+ 0.01mm

1.02mm+ 0.01mm

Dielectric

4.57+ 0.05mm Foam PE

4.57+ 0.05mm Foam PE

4.57+ 0.05mm Foam PE

4.57+ 0.05mm Foam PE

Shield

Bonded AL Foil

Bonded AL Foil

Bonded AL Foil

Bonded AL Foil

Braid coverage

60%~90%

60%~90%

60%~90%

60%~90%

Shield

Al Foil

Al Foil

Braid coverage

40%~60%

Jacket

6.91+0.05mm PVC

6.91+0.05mm

PVC

7.06+0.05mm

PVC

7.54+0.05mm

PVC

Messenger

1.30mm

1.30mm

1.30mm

Characteristics

Nominal Impedance(ohm)

75±3

Nominal Velocity of Propagation(%)

88

Nominal Capacitance(pF/m)

53±3

Sparker Test(AVC)

4000

SRL(dB)

>20

Attenuation

[68^o F(20^o C)]

Frequency (MHz)

Maximum (dB/100 ft.)

Maximum (dB/100 m)

55

1.60

5.25

187

2.85

9.35

300

3.55

11.64

450

4.40

14.43

600

5.10

16.73

750

5.65

18.54

865

6.10

20.01

1000

6.55

21.49

Purchase Notice:
1. Please select the material of inner conductor :BC or CCS
2. Please select the material of jacket:PVC,PVC with RoHs,PE or LSZH.
3. Please select the packing:reel with carton or wooden spool with carton.
4. Please show us your own specification if it's not the same as ours.
5. Please inform us if you have any other requirement.
