Copper Coated Aluminum Wire / CCA Wire
Hangzhou Spring Electronics Co., Ltd.- Application：Local Communication Cable, Coaxial Cable, LAN Cable, Long Distance Symmetric Cable, RF Cable, Submarine Cable
- Conductor Material：BC,CCS,CCA,TC,CU,CCAG
- Cover Material：Non
- Type：Cat 1
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：cca
- Wire Core Material：CCA
- Certification：CE, ISO, RoHS
- Model：Coaxial
- Brand：Fuu
- Transport Package：Carton
- Specification：305m,roll
- Trademark：FUU
- Origin：Made in China
- HS Code：8544200000
- Production Capacity：5000km,Month
Description
Construction Parameters: Nomial diameter Φ /mm 0.2mm Diameter difference ±mm ±0.004mm Copper content % 27 % Density (20 ºC) g/cm3 3.3 g/cm3 Intensity test of the soft state ≥N ≥3.7 N Tensile strength of soft-state≥N/mm2 ≥120 N/mm2 Hard measured intensity ≥N ≥8.4 N Tensile strength of hard-state≥N/mm2 ≥270 N/mm2 Electrical Characteristics: Resistivity (20ºC) ≤Ω.km/mm2 ≤27.5 Ω.km/mm2 Measured resistance (20 ºC) ≤Ω/km ≤875Ω/km Conductivity (20 ºC) ≥% ≥63 % Soft-state elongstion≥% ≥10 % Hard elongation≥% ≥12 % Product Inspection: Inspection Item Standard Requirement (ASTM B 566-93) Inspection Result 1. Surface Bright, Clean, no flaw OK 2. Diameter (mm) 0.2(+/-0.004mm) OK 3. Tensile Strength (N/mm2) ≥120 N/mm2 OK 4. Elongation (%) ≥10 % OK 5. Density (g/cm3) 3.3 (±0.03)g/cm3 OK 6. Resistivity (20ºC) ≤Ω.km/mm2 ≤27.5 Ω.km/mm2 OK 7. Conductivity (%IACS) ≥63 % OK Conclusion Pass Order Informations: Technical Parameter based on customer's requirements Package Please advise the spool size or your special requirements Delivery time Normally 20-25 days after received the deposit. Application braid shielding & cable conductor (single or stranded) for coaxial cable, power cable, signal cable, network cable, data cable, enameled wire etc More informations please contact with us.
