SL 841 C Cable 0.6/1 Kv Combined TPE/PUR Motor Connection Cable

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PUR
  • Insulation Material：TPE
  • Material Shape：Round Wire

Base Info

  • Model NO.：SL 841 C Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, CCC, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemSL 841 C Cable 0.6/1 kV Combined TPE/PUR Motor Connection CableConductor

Bare copper strands

InsulationTPEStrandingcontrol cores 0,34 mm² - 2,5 mm² twisted to pairsScreenpairs wrapped with alu foil, tinned copper braidingWrappingpairs with PETP foilStrandingscreened control pairs and supply cores twisted together in layersWrappingtwo layers non-woven tapeScreenoverall copper screenWrappingnon-woven tapeOuter sheathPURNominal voltagesupply cores: Uo/U 0,6/1 kVPeak operating voltageDIN VDE: control cores max. 350 VTesting voltage

Supply cores:

core/core 4000 V

core/screen 4000 V



Control cores:

core/core 1500 V

core/screen 1500 V

Core numberMulticores (As client's requirement)Min. bending radius

Fixed laying: 5 x d

Flexible application: 10 x d

Continuously flexible: 12 x d

Temperature range

Fixed laying: -50/+90°C

Flexible application: -40/+90°C

Application

SL 841 C is a combined TPE/PUR motor connection cable with high flexibility and overall copper screen 0.6/1 kV. It is recommended for use in highly flexible cable track applications in intelligent industries with servo drives, e.g. automation technologies, machine construction, construction of industrial robots and plants, motive power, control and manufacturing engineering, in handling systems, car manufacturing industry, in cable tracks on wood-working centres, and colour coding acc. to DESINA.
