Ftpcat5e+Message1.3steel Wire LAN Cable Cat5e
Zhejiang Kuayue Cable Co., Ltd.- Application：Local Communication Cable, LAN Cable, Long Distance Symmetric Cable
- Conductor Material：Copper
- Cover Material：PVC
- Type：Cat 5
- Material Shape：Flat Wire
- Conductor Type：Solid
Base Info
- Model NO.：cat5e
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS
- Model：FTP Cat5e
- Brand：Hanli
- Transport Package：305m,Box
- Specification：24AWG
- Trademark：hanli
- Origin：Zhejiang
- HS Code：8544491100
- Production Capacity：3000000m,Month
Description
Product Name/Code: FTP Cat 5E PVCPerformance Application: Frequency RL Attenuation NEXT PSNEXT 100 Base-T4 (MHz) (dB) (dB/100m) 100 Base-TX min. max min (dB) min (dB) 100VG - AnyLAN 0.722 22.60 1.82 67.00 64.00 1000 Base-T (Gigabit Ethernet) 1.000 23.10 2.00 65.30 62.30 155 Mbps ATM 4.000 23.00 4.10 56.30 53.30 622 Mbps AT 8.000 24.50 5.80 51.80 48.80 Reference Standard 10.00 25.00 6.50 50.30 47.30 EIA/TIA 568B & ISO/IEC 11801 16.00 25.00 8.20 47.30 44.30 Cable Construction 20.00 25.00 9.30 45.80 42.80 Conductor Solid Bare Copper 25.00 24.20 10.23 44.30 41.30 AWG 24 31.25 23.30 11.71 42.90 39.90 Conductor Diameter(mm) 0.53 62.50 20.70 17.25 38.40 35.40 Insulation Solid PE 100.00 19.24 22.00 35.30 32.30 Average Thickness (mm) 0.2 Frequency ELFEXT PSELFEXT ACR Insulation Diameter(mm) 1.00 (MHz) Drain wire Tinned copper min (dB) min (dB) Construction (mm) 7/0.2 0.722 66.00 63.00 65.00 Al foil Aluminium/PET fiol 1.000 63.8 60.8 63.30 4.000 51.7 48.7 52.20 8.000 45.7 42.7 46.00 Sheathing PVC /FRPVC 10.00 43.8 40.8 43.80 Thickness(mm) 1.4 16.00 39.7 36.7 39.10 Diameter(mm) 5.8 20.00 37.7 34.7 36.50 25.00 35.8 32.8 33.90 Core Identificatin/Color Code According to customer request 31.25 33.9 30.9 31.20 Bending Radius 6xOverall Diameter 62.50 27.8 24.8 21.40 100.00 23.8 20.8 13.30 Fire Performance Electrical Performance Flame propagation Test to IEC 332 Part 1(PVC)
Flame Propagation Test to IEC 60332 Part 1 and Part 3(FRPVC) Max.Conductor DC Resistance at 20 ºC(Ω/Km) <93.8 Operating Temperature( ºC ) 70 Velocity of propagation 68% Impedance(ohm) 100±15
Welcome to visit our factory and get our samples.
Your inquiry will be answered within 24 hours .Wishing to be your long- term partner ,please feel free to contact me ,we will do our best for you.
Choose us, won't make you disappointed:
1.6years manufactory experience
2.OEM/ODM available
3.Steady product quality
4.Strict quality control
5.Strictly conform to CE,ROHS,Iso9001
6.Quick delivery time(20ft,25days)
