GYXTW-12b1 Fiber Optical Cable Waterproof Field Cable
Hangzhou Softel Optic Co., Ltd.- Application：Fiber Optic Cable
- Conductor Material：Fiber
- Cover Material：PE
- Type：GYXTW-12b1
- Certification：CE, ISO
- Brand：Softel
Base Info
- Model NO.：GYXTW-12B1
- Apply for：Aerial
- Fiber Count：1,2,4,6,8 as Per Your Design
- Cable Type：Sm or Mm
- Fiber Type：9,125 (G657A2)
- Material of Jacket：MDPE,HDPE
- Fiber Optic Cable Tube：Central Loose Tube
- Model Name：Fiber Optic Cable
- Model No.：Gjyxfch-8b6.A2
- Delivery Time：10 Days
- MOQ：2 Drum
- Transport Package：4km Wooden Drum
- Trademark：SOFTEL
- Origin：China
- HS Code：8517622990
- Production Capacity：1000km Per Month
Description
1000Note: Mechanical sizes are nominal values.
3. Characteristic of Optical Cable
3.1 Min. bending radius for installation
Static: 15 x cable diameter
Dynamic: 20 x cable diameter
3.2 Application temperature range
Operation: - 40ºC ~ +60ºC
Installation: -10ºC ~ +60ºC
Storage/transportation: - 40ºC ~ +60ºC
3.3 Main mechanical & environmental performance test
4. Characteristic of Optical Fiber
G652D fiber information
Mode field diameter (1310nm): 9.2mm±0.4mm
Mode field diameter (1550nm): 10.4mm±0.8mm
Cut off wavelength of cabled fiber (lcc): £1260nm
Attenuation at 1310nm: £0.36dB/km
Attenuation at 1550nm: £0.22dB/km
Bending loss at 1550nm (100 turns, 30mm radius): £0.05dB
Dispersion in the range 1288 to 1339nm: £3.5ps/ (nm•km)
Dispersion at 1550nm: £18ps/ (nm•km)
Dispersion slope at zero dispersion wavelength: £0.092ps/ (nm2•km)
3. Characteristic of Optical Cable
3.1 Min. bending radius for installation
Static: 15 x cable diameter
Dynamic: 20 x cable diameter
3.2 Application temperature range
Operation: - 40ºC ~ +60ºC
Installation: -10ºC ~ +60ºC
Storage/transportation: - 40ºC ~ +60ºC
3.3 Main mechanical & environmental performance test
| Item | Test Method | Acceptance Condition |
| Tensile Strength IEC 60794-1-2-E1 | - Load: Short term tension - Length of cable: about 50m - Load time: 1min | - Fiber strain £ 0.6% - No fiber break and no sheath damage. |
| Crush Test IEC 60794-1-2-E3 | - Load: Short term crush - Load time: 1min | - Loss change £ 0.1dB@1550nm - No fiber break and no sheath damage. |
G652D fiber information
Mode field diameter (1310nm): 9.2mm±0.4mm
Mode field diameter (1550nm): 10.4mm±0.8mm
Cut off wavelength of cabled fiber (lcc): £1260nm
Attenuation at 1310nm: £0.36dB/km
Attenuation at 1550nm: £0.22dB/km
Bending loss at 1550nm (100 turns, 30mm radius): £0.05dB
Dispersion in the range 1288 to 1339nm: £3.5ps/ (nm•km)
Dispersion at 1550nm: £18ps/ (nm•km)
Dispersion slope at zero dispersion wavelength: £0.092ps/ (nm2•km)
