Rubber H07zz-F Cable LSZH 450/750V Copper Cable 1.5mm 2.5mm 4mm 6mm

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Pcp (Polychloroprene)
  • Insulation Material：Epr (Ethylene Propylene Rubber)
  • Material Shape：Round Wire

Base Info

  • Model NO.：H07ZZ-F Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemRubber H07ZZ-F Cable ConductorClass 5 flexible copper conductorInsulationLSZH (Low Smoke Zero Halogen) cross-linked compoundOuter sheathLSZH (Low Smoke Zero Halogen) cross-linked compoundCore NumberMulticores (As client's requirement)Temperature rangeFixed: -20°C to +90°C
Flexed: -5°C to +50°CRated voltageUo/U 450/750 VColorOptionalApplicationFor installation where fire, smoke emission and toxic fumes create a potential threat to life and equipment. Examples of use include supplying mobile power units, UPS installations, stage lighting and audio visual equipment. This cable will withstand medium mechanical stresses and is suitable for both installation indoors and outdoors
