Low Voltage BS5467 Swa XLPE Cable Armoured Power Cables
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial, Power Station
- Voltage：Low and Medium Voltage Cable
- Current：AC Cable
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：bs5467
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE
- Model：BS5467 Cable
- Brand：Hongda
- Armoured：Steel Wire or Steel Tape
- Rated Voltage：600,1000V
- Minimum Bending Radius：8 X Overall Diameter
- Transport Package：Steel & Wooden Drum
- Specification：1.5mm2 to 400mm2
- Trademark：Hongda Cable
- Origin：China
- HS Code：8544492100
- Production Capacity：300km,Month
Description
No. of CoresNominal Cross Sectional Area Nominal Thickness of Insulation Nominal Overall Diameter mm Nominal Weight mm² mm Under Armour Overall kg/km 2 1.5 0.6 7.3 12.1 302 2 2.5 0.7 8.5 13.6 346 2 4 0.7 9.4 14.7 410 2 6 0.7 10.5 15.9 499 2 10 0.7 12.3 18 648 2 16 0.7 14.3 20.4 978 2 25 0.9 14.7 20.4 1290 2 35 0.9 16.8 23.3 1500 2 50 1 19 25.8 1890 2 70 1.1 22 29 2450 2 95 1.1 25.1 33.1 3300 2 120 1.2 27.9 36.1 4020 2 150 1.4 30.9 39.3 4750 3 1,5 0.6 7.8 12.6 330 3 2.5 0.7 9.2 14.1 390 3 4 0.7 10 15.3 464 3 6 0.7 11.2 16.6 568 3 10 0.7 13.1 19.5 866 3 16 0.7 15.3 21.6 1152 3 25 0.9 18.9 23.6 1800 3 35 0.9 21.3 25.7 2230 3 50 1 21.7 28.5 2490 3 70 1.1 25.2 32.2 3290 3 95 1.1 28.8 37 4440 3 120 1.2 32 40.4 5470 3 150 1.4 35.9 45.5 6930 3 185 1.6 40 49.8 8350 3 240 1.7 44.9 55.1 10400 3 300 1.8 49.8 60.2 12600 3 400 2 55.8 66.6 14600 4 1.5 0.6 8.5 13.3 365 4 2.5 0.7 9.9 15 438 4 4 0.7 11 16.4 532 4 6 0.7 12.3 18.7 764 4 10 0.7 14.5 21.1 1013 4 16 0.7 17 23.4 1360 4 25 0.9 21 26.1 2160 4 35 0.9 23.6 28.6 2690 4 50 1 25 32 3130 4 70 1.1 29.5 37.7 4500 4 95 1.1 33.3 41.7 5600 4 120 1.2 37.5 47.1 7400 4 150 1.4 41.6 51.4 8780 4 185 1.6 46.4 56.6 10630 4 240 1.7 52.6 63 13390 4 300 1.8 58 68.8 16290 4 400 2 65.4 78.1 19800 5 1.5 0.6 9.7 14.3 410 5 2.5 0.7 11.7 16.1 470 5 4 0.7 13 17.8 710 5 6 0.7 14.5 20 876 5 10 0.7 17.2 22.9 1165 5 16 0.7 20 26.6 1742 5 25 0.9 24.7 31.5 2323 5 35 0.9 27.8 34.8 2932 5 50 1 32.4 40.4 4192 7 1.5 0.6 10.2 15.2 470 7 2.5 0.7 12.3 17.1 600 7 4 0.7 13.6 19.1 881 12 1.5 0.6 13.7 19.4 780 12 2.5 0.7 16.3 22.4 1000 19 1.5 0.6 16.2 22.2 1000 19 2.5 0.7 19.9 26.6 1540 27 1.5 0.6 20 26.7 1500 27 2.5 0.7 24 30.7 1950 37 1.5 0.6 22.3 29 1800 37 2.5 0.7 26.9 33.8 2350
Class 2 Stranded Conductors for Single Core and Multi-Core CablesMinimum No. Of Wires In ConductorMaximum Resistance
of Conductor At 20ºC mm² Circular Circular Compacted Shaped Annealed Copper Conductor Cu Al Cu Al Cu Al Plain Wires ohms/km 1.5 7 - 6 - - - 12.1 2.5 7 - 6 - - - 7.41 4 7 - 6 - - - 4.61 6 7 - 6 - - - 3.08 10 7 7 6 6 - - 1.83 16 7 7 6 6 - - 1.15 25 7 7 6 6 6 6 0.727 35 7 7 6 6 6 6 0.524 50 19 19 6 6 6 6 0.387 70 19 19 12 12 12 12 0.268 95 19 19 15 15 15 15 0.193 120 37 37 18 15 18 15 0.153 150 37 37 18 15 18 15 0.124 185 37 37 30 30 30 30 0.0991 240 37 37 34 30 34 30 0.0754 300 61 61 34 30 34 30 0.0601 400 61 61 53 53 53 53 0.047
Whilst HONGDA CABLE plc endeavours to ensure the information on the website, specification sheets and all other technical information is accurate, the information is for guidance only and it is subject to change without notice or liability. HONGDA Cable Plc is not responsible for the consequences of any inadequacies, inaccuracies or other deficiencies contained therein. When selecting cable accessories, please note that the actual cable dimensions may vary due to manufacturing tolerances.
Class 2 Stranded Conductors for Single Core and Multi-Core CablesMinimum No. Of Wires In Conductor
of Conductor At 20ºC
Whilst HONGDA CABLE plc endeavours to ensure the information on the website, specification sheets and all other technical information is accurate, the information is for guidance only and it is subject to change without notice or liability. HONGDA Cable Plc is not responsible for the consequences of any inadequacies, inaccuracies or other deficiencies contained therein. When selecting cable accessories, please note that the actual cable dimensions may vary due to manufacturing tolerances.
