Fror - 300/500V and 450/750V Cable for Connections and Movable Equipment

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Industrial Cable
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC

Base Info

  • Model NO.：FROR Cable
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemFROR Cable for Connections and Movable EquipmentConductorFine bare copper strandsInsulationPVCOuter SheathPVCCore NumberMulticores (As client's requirement)Rated Voltage 300/500 volts, 450/750 voltsTest Voltage2.5 KVMinimum Bending RadiusFlexing: 10 x Ø
Static: 4 x ØTemperature RangeFlexing Temperature: -15ºC to +70 ºC
Static Temperature: 0ºC to +70 ºCColorOptionalApplicationThese flexible cables insulated with Standard and Approval-quality PVC plus a heavyweight PVC sheath, they are suitable for connections and movable equipment, even in places of public show and entertainment. Can be installed inside, in dry or humid environments (AD2), and for temporary use outside and not permissible under the laying plaster or underground, even if protected.
