Fire Resistant Nhxh Fe180-E30 0.6/1kv Low Smoke Zero Halogen Safety Cables

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：LSZH
  • Insulation Material：LSZH
  • Material Shape：Round Wire

Base Info

  • Model NO.：NHXH Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemNHXH FE180-E30 Cables ConductorRE: Class 1 solid copper conductor
RM: Class 2 stranded copper conductorInsulationLSZH (Low Smoke Zero Halogen)Inner SheathLSZH (Low Smoke Zero Halogen)Outer sheathLSZH (Low Smoke Zero Halogen)Core NumberMulticores (As client's requirement)Temperature range-5°C to +90°CRated voltageUo/U 0.6/1 kVColorOptionalApplicationSafety cables are used in all locations where a high degree of protection against fire and fire damage has to be provided for human life and equipment and are, therefore, subject to high security requirements. These cables may be used indoors and outdoors. They may not be installed directly into the ground or into water. Fire resistant to FE 180 and Circuit Integrity to E 30.
