Basic Info.

Model NO. THW TW Material Shape Round Wire Range of Application Housing and Building Certification ISO9001, CCC Brand Hongda Color Red Yellow Green Blue Black White Transport Package on The Drum or on The Pallent Specification 14 12 10 8 6 4 2 1 1/0 2/0 Trademark hongda Origin Henan HS Code 8544492100 Production Capacity 10000m/Day

Product Description

THW Cable 2AWG



Description

Soft copper conductor, PVC insulated.

Construction

Conductor:  compressed strand soft copper

Insulation: Polyvinyl Chloride (PVC 75° C), flame retardant

Options

Available upon request, THW-LS (Low Smoke emission), THW-SR

(Sunlight Resistant) and with insulation Gasoline and Oil resistant

G&O (different types and grades of resistance to oil and gasoline)

Characteristics

Operating Temperature

Dry Locations 75° C.

Wet Locations 75° C

Operating Voltage 600 V.

Standards

ASTM B3, NTC 359. Soft copper wire.

ASTM B8, NTC 307. Concentric Lay Stranded copper conductors.

ASTM B787. 19 Wire Combination Unilay Stranded Copper conductors for subsequent insulation

UL 1581, NTC-3203. Reference Standard for Electrical Wires, Cables and Flexible Cords.

UL 83, NTC-1332. Thermoplastic insulated Wires and Cables.

Colors

Sizes 14 to 6 AWG: black, white, red, green, yellow, blue. Sizes 4 AWG and greater: black

THW Cable Packaging

Sizes 14 to 10 AWG: 100 m spools covered with plastic thermo pack, in corrugated carton boxes.

Sizes 8 and 6: 2000 m reels,

Sizes 4 to 4/0 AWG:1000 m reels.

Sizes 250 to 500 kcmil: 500 m reels.

Note: Other configurations, sizes, colors and length not specified herein are available upon request.
