Fusion Splicer Fiber Optic Splicing Machine with Fiber Cleaver

Hangzhou Softel Optic Co., Ltd.
  • Type：Fiber Splicer
  • Certification：RoHS
  • Customized：Customized
  • Condition：New
  • Feature：Insulation
  • Splicer Time：7s

Base Info

  • Model NO.：FSP-06
  • Tension Test：1.8-2.2n
  • Splicer Heating Time：26 Seconds for 60mm and 40mm Shrinkable Sleeves
  • Weight：1.6kg Including Battery
  • Size：200mm(L)X123mm(W)X95mm
  • Battery Capacity：4400mAh Li-Battery, Typical 220 Cycles(Splice and
  • MOQ：1PC
  • Transport Package：Standard Carton
  • Specification：ROhS
  • Trademark：SOFTEL OEM
  • Origin：Zhejiang, China
  • HS Code：8517622990
  • Production Capacity：1000 PCS,Month

Description

Standard  Package:







Main machine *1

Fiber Cleaver *1

Electrodes *1 pair

Fiber Stripper *1

Drop Cable Stripper *1

Adaptor *1

  Manual(CD) *1

Power Cord *1

Carrying Case *1

Strap *1


ParametersApplicable fiber

SM(G.652), MM(G.651), DS(G.653), NZDS(G.655),

others(including G.657)

Applicable fiber

SM(ITU-T G.652),MM(ITU-T G.651),DS(ITU-T G.653),

NZDS(ITU-T G.655)

Diameter of cladding80 -150μmDiameter of coating160 - 900μmTypical splice lossSM:0.02dB, MM:0.01dB, DS:0.04dB, NZDS:0.04dBReturn loss>60dbFiber cleaved length

10-16mm (coating diameter< 250μm ), 16mm

(coating diameter: 250-1000μm )

Splicing program40 groupsOperate modeManual, AutomaticAuto-heatingAvailableTypical splicing time7secondsTube heating time26 seconds for 60mm and 40mm shrinkable sleevesFiber view magnification250X(X or Y view), 125X(X and Y view)

Viewing method

and display

2 CMOS cameras, 4.3 inch color LCD monitorStorage of splice result4000 resultsLoss evaluationAvailableTension test1.8-2.2NInterfaceGUI menu interface, easier operationBattery capacity4400mAh Li-battery, typical 220 cycles(splice and tube heat)Power supplyAdaptor, input: AC100-240V(50/60HZ),output: DC11-13.5VElectrode lifeMore than 4000 ARC discharges, can be replaced convenientlyTerminals

USB 2.0 port, for uploading splice results and

upgrading software

Operating conditionAltitude: 0-5000m, Humidity: 0-95%, Temperature: -10ºC~+50ºC;Wind speed:max 15m/sDimension200mm(L)x123mm(W)x95mm(H)Weight1.6kg including battery
