| Item | PVC Control and Connection Cable |
| Conductor | Copper wire bare, finely stranded acc. to DIN VDE 0295 class 5 / IEC 60228 class 5 |
| Insulation | PVC acc. to DIN VDE 0207-363-3 / DIN EN 50363-3 (compound type TI2) |
| Outer Sheath | PVC acc. to DIN VDE 0207-363-4-1 / DIN EN 50363-4-1 (compound type TM2) |
| Inner Sheath | PVC |
| Screen | Braided screen of tinned copper, approx. coverage 85% |
| Nominal Voltage | AC Uo/U 600/1000 V |
| Temperature Range | Flexible -15°C to +80°C
Fixed -40°C to +80°C |
| Color | Optional |
| Certification | CE |
| Application | Used as a connection and control cable in machine tools, assembly lines and conveyor belts, production lines, plant construction, heating and air-conditioning technology and in smelters and steel mills. Suitable for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, as well as outdoors (fixed installation). May not be laid directly in soil (suitable for direct burial starting with an outer diameter of 20 mm) or water. Due to its extended nominal voltage range and good UV resistance, this cable is primarily used in Southern Europe, Arabic, Asian and Eastern countries. Due to the high screening density, interference-free transmission of signals or pulses is ensured. |
