Cu/XLPE/Swa/PVC, 0.6/1 Kv, Steel Wire Armored (SWA) Power Cable (BS 5467)

Jiangsu Boan Cable Co., Ltd.
  • Application：Construction, Underground
  • Voltage：Low and Medium Voltage Cable
  • Current：DC Cable
  • Insulation Material：XLPE
  • Sheath Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：CU,XLPE,SWA,PVC
  • Wire Core Material：Bare Copper Wire
  • Certification：ISO, CCC, CE
  • Model：Cu,XLPE,Swa,PVC
  • Brand：Boan
  • Referred Standard：BS 5467
  • Rated Voltage：0.6,1 Kv
  • Number of Cores：2-4
  • Size Range：4-300 mm2
  • Class of Conductor：2
  • Type of Armour：Galvanized Steel Wire
  • Transport Package：Heated Steel-Wooden Drum,Steel Drum
  • Specification：SGS, CE
  • Trademark：DingAn
  • Origin：Jiangsu Yixing, China
  • HS Code：8544492100
  • Production Capacity：38000 Km,Year

Description

SectionMax. Conductor ResistanceCurrent RatingOverall DiameterCable WeightDC at 20AC at 70Laid in GroundLaid in DuctsLaid in Free AirNo. x mm2
Ω/kmΩ/kmAAAmmkg/kmTwo Core Cables4rm4.61005.880051414714.74456rm3.08003.930064536115.752010rm1.83002.330083708017.164016rm1.15001.47001078410619.893025rm0.72700.927014010814023.2129035rm0.52400.669016813516826.51770Three Core Cables4rm4.61005.880046374215.35006rm3.08003.930058465116.459510rm1.83002.330076616919.181516rm1.15001.470098769021.5106525rm0.72700.927013010312026.2166535sm0.52400.669015812214725.71865Four Core Cables4rm4.61005.880046374216.45756rm3.08003.930058465118.579510rm1.83002.330076616920.496016rm1.15001.470098769023.1128025rm0.72700.927013010312228.2199035sm0.52400.669015812214728.7233550sm0.38700.494018514518432.4297570sm0.26800.343022018022037.4427095sm0.19300.248026521027340.15375120sm0.15300.197030524531545.46980150sm0.12400.160033527537549.98280185sm0.09910.129037531041054.910103240sm0.07540.099043536548860.912660300sm0.06010.081049040556266.515305
