• Model NO.：H07RN-F,yc
• Wire Core Material：Copper or Aluminum
• Certification：ISO, CCC, CE, RoHS, UL, VDE
• Model：H07rn-F,Yz
• Brand：Feiya
• Temperature Range：-25°c to +60°c
• OEM&ODM：Yes
• Rated Voltage：450,750V
• Operating Environment：Handling Equipment, Mobile Power Supplies, Worksit
• Other Service：Can Be Customized
• Colors：Can Be Customized
• Transport Package：Wooden Box Packing or Pallet Shipping Containers
• Specification：copper,aluminum,rubber
• Trademark：Feiya
• Origin：China
• HS Code：8544
• Production Capacity：80000 Meter,Meters Per Month

H07RN-F Cable Construction:

• Conductor: Stranded Bare Copper acc. to IEC 60228, EN 60228, VDE 0295, class 5
• Insulation: Synthetic Rubber, EI4 acc. to DIN VDE 0282 part 1 + HD 22.1
• Conductor Color Coding: acc. to HD 308 (VDE 0293-308)
• Conductor Stranding: from 2 conductors stranded in layers
• Jacket: Synthetic Rubber, EM2 acc. to DIN VDE 0282 part 1 + HD 22.1
• Jacket Color: Black

H07RN-F Cable Technical Data:

• Nominal Voltage: Uo/U 450/750 volts
• Testing Voltage U: 2500 volts acc. to DIN VDE 0282 part 2 + HD 22.2
• Min. Bending Radius: 15 x O.D.
