318-B-H05 Z1z1-F Flexible 3X0.75mm2 1.5mm2 Cable Low Smoke Zero Halogen Cables

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：LSZH
  • Insulation Material：LSZH
  • Material Shape：Round Wire

Base Info

  • Model NO.：318-B-H05 Z1Z1-F Cable
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

Item318-B-H05 Z1Z1-F Flexible 3x0.75mm2 1.5mm2 Cable Low Smoke Zero Halogen CablesConductorPlain annealed flexible stranded copper conductorInsulationLow Smoke Zero Halogen (LSZH)Outer SheathLow Smoke Zero Halogen (LSZH)Core NumberMultcores (As client's require)Temperature rangeFixed: -15ºC to +70ºCRated voltage300/500 VColorOptionalApplication318*B zero halogen flexible cord cables are used as an indoor general wiring cable, primarily for installations in public areas. They are most commonly used for pendant lighting or as a general supply lead within public areas such as hospitals, shopping centres or airports. They are generally installed where fire, smoke emission and toxic fumes would create a hazard, should a fire occur.
