16mm 3 Core XLPE PVC Aluminium Steel Tape Armoured Power Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial, Power Station, Copper Conductor 4 Core 120mm2 XLPE Insulated Armo
- Voltage：Low and Medium Voltage Cable
- Current：DC Cable
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：IEC60502
- Wire Core Material：Tinned Wire
- Certification：ISO, CCC, CE
- Model：YJV
- Brand：Hongda
- Insulation Color(S)：Natural , Red , Yellow , Blue , Green etc.
- Outer Sheath Color：Black etc.
- No. of Cores：3 Core
- Cross Section：240 mm2
- Packing Length：According to Your Request
- Long‐term Working Temperature：90°c
- Max. Temperature in Short Circuit：160°c ,250°c
- Rated Voltage：3.6,6kv 7.5,15kv
- Design Standard：IEC 60502-1, IEC 60502-2, IEC 60227, IEC 60228
- Certificate：ISO 14001 , ISO 9001 , Ohasa 18001 , CCC
- Warranty：Three Years
- Transport Package：by Sea
- Specification：copper xlpe insulated pvc sheathed 4 core 120mm2
- Trademark：HENAN HONGDA
- Origin：China
- HS Code：85444929
- Production Capacity：5000
Description
YJV32
YJLV32mm2 mm mm mm mm mm kg/km kg/km A A A A 3×4 RE 2.24 0.7 1.25 1.8 17.1 621 546 37 28 46 35 3×6 RE 2.76 0.7 1.25 1.8 17.8 700 591 47 37 56 46 3×10 CC 3.8 0.7 1.6 1.8 19.5 885 695 64 47 76 56 3×16 CC 4.8 0.7 1.6 1.8 21.5 1141 840 84 64 98 76 3×25 CC 6.0 0.9 1.6 1.8 26.6 1670 1201 115 84 126 98 3×35 CC 7.0 0.9 1.6 1.8 28.8 2033 1384 141 115 152 126 3×50 SM 8.0 1.0 1.6 1.8 31.8 2513 1635 172 141 181 152 3×70 SM 9.5 1.1 2.0 2.0 36.1 3502 2231 218 172 222 181 3×95 SM 11.0 1.1 2.0 2.2 39.4 4392 2632 269 218 267 222 3×120 SM 12.4 1.2 2.0 2.3 42.4 5258 3033 313 269 305 267 3×150 SM 13.8 1.4 2.5 2.4 46.9 6706 3972 359 313 344 305 3×185 SM 15.4 1.6 2.5 2.6 51.5 8104 4671 405 359 383 344 3×240 SM 17.5 1.7 2.5 2.7 56.1 10062 5557 451 405 442 383 3×300 SM 19.6 1.8 2.5 2.9 60.6 12082 6451 497 451 461 422
YJLV32
