High Speed LAN Cat7 Communication Network Copper Cable with Reduced Weight for Subway/Cloud Computing Center/Data Room

Metallurgica Bresciana (Maanshan) Special Cables Co., Ltd.
  • Type：Insulated
  • Conductor Type：Conforms to IEC 60228 Category 6 Conductor
  • Application：Overhead, Underground
  • Conductor Material：Bare Soft Copper Wire
  • Sheath Material：Crosslinking
  • Insulation Material：Foamed Polyethylene

Base Info

  • Model NO.：CAT7 S,FTP 4x2x24AWG PATCH
  • Material Shape：Round Wire
  • Range of Application：Flame Retardant
  • Certification：ISO9001, Iris Certificate
  • Cable Structure：Twisted
  • Insulation Diameter：1.53mm
  • Shield Material：Aluminium Foil
  • Shield Coverage：Min.90%
  • Casing Diameter：8.60mm
  • Casing Thickness：0.70mm
  • Working Temperature：-40 ~ +90ºC
  • Usage：Cloud Computing Center,Data Room,Rail,etc.
  • Color：Black or Customized
  • Guideline：IEC 61156-6, Tj,Cl 313-2014
  • MOQ：100 Meters
  • Transport Package：Drum,Bobbin,Coil
  • Specification：98kg,km
  • Trademark：METALLURGICA BRESCIANA
  • Origin：Anhui, China
  • Production Capacity：1000000meters,Month

Description

Overview Product Description

Mechanical Physical PropertiesWorking temperature range-40 ~ +90ºCOperating voltage300VWeight98kg/kmMinimum bending radius (fixed)69mmSheath tensile strenght≥10MPaSheath elongation≥125%Sheath aging conditions120x240ºCxhChange rate of sheath tensile strength≤30%Sheath elongation resistance rate of change≤30%Sheath thermal extension test conditions200x15ºCxminThermal extension test mechanical stress20N/cm2Elongation rate under load in hot extension test≤100%Hot elongation test elongation rate when unloading≤25%High frequency electrical performanceCharacteristic impedance (Z0)100±5Ω (1~600MHz)Attenuation (ATT)Compliant with IEC61156-6Return loss (RL)Compliant with IEC61156-6Near-end crosstalk (NEXT)Compliant with IEC61156-6Near-end crosstalk power sum (PSNEXT)Compliant with IEC61156-6Equal level far-end crosstalk (ACR-F)Compliant with IEC61156-6Equal level far-end crosstalk power sum (PSACR-F)Complyiant with IEC61156-6Delay (PD)Compliant with IEC61156-6

High Speed LAN Cat7 Communication Network Copper Cable with Reduced Weight for Subway/Cloud Computing Center/Data Room

Features

Production Line



Our Advantages

Company Profile

Our Customers

The quality of cables we are making are the key factor for the safety of mass transportation. We are dedicated to the satisfaction and success of every customer.
High Speed LAN Cat7 Communication Network Copper Cable with Reduced Weight for Subway/Cloud Computing Center/Data Room

Certifications

High Speed LAN Cat7 Communication Network Copper Cable with Reduced Weight for Subway/Cloud Computing Center/Data Room

FAQ

Q1: Are you the real factory?
A:Yes, we are one of the production plant of our international company.


Q2: What is your main products?
A:Cables for different industries and uses. We offer customized solutions.

Q3: What is your delivery time?
A: Withing 15 days for about 30km of standard product. Time is variable for special solutions.

Q4: MOQ: what is your minimum quantity?
A: 300 meters.


Q5: Package & Shipping & Delivery
A: For large orders:  customized.
