Outdoor 2 Core FTTH Cable with Self-Supporting Figure 8 Bow-Type Design and Steel Messager
DONGGUAN TW-SCIE CO., LTD.- Application：Telecommunication Cable
- Type：Fiber Optics
- Certification：RoHS, UL, CE, ISO9001
- Brand：OEM
- Sheath Material：LSZH
- Cable Type：FTTH
Base Info
- Model NO.：FTTH
- Cable Structure：Customized
- Cable Diameter：2.0*3.0,2.0*5.0
- Cable Color：Customized
- Brand of Fiber：Corning ,Yofc
- Fiber Counts：1-4 Cores
- Installation：Indoor ,Outdoor Use
- Strength Member：FRP or Steel
- Transport Package：Wooden Drum
- Specification：Customized
- Trademark：Customized
- Origin：China (Mainland)
- HS Code：8544700000
- Production Capacity：300km,Day
Description
Jacket
Dimension
5.2±0.2mm×2.0±0.1mm
Material
LSZH
Color
Black
Mechanical and Environmental Characteristics
Items
Unite
Specifications
Tension (Long Term)
N
300
Tension (Short Term)
N
600
Crush (Long Term)
N/10cm
1000
Crush (Short Term)
N/10cm
2200
Min. Bend Radius (Dynamic)
mm
20D
Min. Bend Radius (Static)
mm
10D
Installation Temperature
ºC
-20~+60
Operating Temperature
ºC
-40~+70
Storage Temperature
ºC
-40~+70
