• Model NO.：GYXTC8S
• Core：2-24
• Certification：RoHS, UL, CE, ISO9001, VDE, CCC
• Brand：Efon
• Sheath Material：LSZH,PE Sheath,Flame Retardant Sheath,Anti-Rodent
• Fiber Type：Sm G652D
• Fiber Material：Doped Silica
• Fiber：Single Mode
• Armored：Aluminium Tape,Steel Tape
• Loose Tube：Central Loose Tube
• Diameter of Self Support Member：0.9mm*7;1.0mm*7;1.2mm*7;1.5mm*7
• Material of Jacket：LSZH,PE ,Flame Retardant Sheath
• Bending Radius：Static 10*Cable-D: Dynamic 20*Cable-D
• Max Tension：4000n
• Applications：for Hanging on Poles
• Transport Package：Wooden Drum Iron-Wooden Drum with Fumigated or Not
• Specification：CE
• Trademark：OEM
• Origin：China
• HS Code：85447000
• Production Capacity：300km,Week

Mechanical Performance

Max Tension Performance

IEC 60794-1-2-E

Max. Operation Tension

IEC 60794-1-2-E1

Crush Test

IEC 6079 -1-2-E3

Impact Test

IEC 60794-1-2-E4

Repeated Bending

IEC 60794-1-2-E6

Torsion Test

IEC 60794-1-2-E7

Cable bend

IEC 60794-1-2-E11A

Attenuation Coefficient

ITU-T G.652

Structural Test

IEC-60793-1-20

Environmental Performance

Temperature Cycling

IEC 60794-1-2-F1

Water Penetration

IEC 60794-1-2-F5B

Filing Compound Flow

IEC 60794-1-E1

Structure and Technical SpecificationsFiber Count2-810-1214-24Diameter of Self support member (Steel wire)7x0.9mm7x1.0mm7x1.2mmDiameter of Loose tube(mm)2.42.42.8Diameter of Cable(mm)7.37.37.7Gross weight(Kg/Km)___Min. bending radiusStatic 10xD     Dynamic 20xDMax. tensile force, N(short term)2700N3000N4000NMax. tensile force, N(long term)800N1000N1500NMax Crush Resistance(N/100mm)Short term/ Long term   1000N/300NAllowable Temperaturesoperation-40°C - +60°Cstorage-50°C - +70°Cinstall.-20°C - +50°C
