Servo 2y- (St) -Cy-587 Low Capacitance Cable for Frequency Converters 0.6/1kv

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Medium Strain Application
  • Conductor Material：Copper
  • Sheath Material：Halogen-Free
  • Insulation Material：PE

Base Info

  • Model NO.：Servo 2Y-(St)-CY-587 Low Capacitance Cable
  • Material Shape：Round Wire
  • Range of Application：Medium Strain Application
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemServo 2Y-(St)-CY-587 Low Capacitance CableConductorCopper wire bareInsulationPEScreen1Aluminium foilScreen2Tinned copper braidingOuter sheathHalogen-freeVoltage Rating600/1000 VTest Voltage4000VTemperaturefixed installation: -30°C to +80°C
flexible application: -5°C to +70°CColorOptionalApplicationServo 2Y-(St)-CY-587 double shielded are designed for application with high EMC requirements to connect motors and frequency converters and can be used for medium strain application in dry and damp areas but not outdoors. The low capacitance PE core insulation allows a disturbance free application in frequency converters, servo and DNC-motors especially where longer cable lengths are needed. For optimized EMC-Design, cables with three core protective conductor should be used.
