LAN Cable with LSZH 23AWG UTP CAT6
Hangzhou Risun Cable Co., Ltd.- Application：Local Communication Cable, LAN Cable
- Conductor Material：Bc,Cu,CCA,Tc,CCS
- Cover Material：PVC,PE,LSZH
- Type：Cat 6
- Material Shape：Round Wire
- Conductor Type：Solid
Base Info
- Model NO.：UTP Cat6
- Wire Core Material：Bare Copper Wire
- Certification：CE, ISO, RoHS, ETL SGS CPR
- Brand：Risun or OEM
- Cores：8
- Conductor：23AWG Copper
- Filler：Yess
- Transport Package：305m,Wooden Reel,CTN
- Specification：ETL, CE, ROHS, ISO9001
- Trademark：RISUN or OEM
- Origin：Hangzhou, China(Mainland)
- HS Code：8544491100
- Production Capacity：20000 Boxes , Month
Description
ConstructionConductor 23AWG BC/CU/CCA/CCS Insulation HDPE 1.0±0.02mm Cores/Pairs 8/4 Sheath 6.20±0.1mm PVC (FR,RoHS,UV)/ LSOH / PE
Mechanical PropertiesElongation Min. 300% Temperature Range -20 up to +75°C Tensile strength Min. 1.68Kg/mm2 Conductor Resistance Max. 9.38 ohm/100m Resistance Unbalance Max. 2% Insulation Resistance 150 ohm/KM Mutual Capacitance Max. 5600pF/100m Cpacitance Unbalance Max. 330pF/100m Impendance 100±15 ohm Spark Test 2000V Velocity Propagation 67%
Technical Data Attenuation RL Next PS Next (MHz) (db/100m) (db) (db) (db/100m) 4MHz 3.8 23 66.3 63.3 8MHz 5.3 24.5 61.8 58.8 10MHz 6.0 25 60.3 57.3 16MHz 7.6 25 57.2 54.2 20MHz 8.5 25 55.8 52.8 25MHz 9.5 24.3 54.3 51.3 31.25MHz 10.7 23.6 52.9 49.9 62.5MHz 15.4 21.5 48.4 45.4 100MHz 19.8 20.1 45.3 42.3 200MHz 29 18.0 40.8 37.8 250MHz 32.8 17.3 39.3 36.3
Hangzhou Risun Cable Co., Ltd specializes in producing Cables: UTP CAT5e, UTP CAT6, FTP CAT5e, FTP CAT6, SFTP CAT5e, SFTP CAT6, SF/UTP CAT5e, SF/UTP CAT6, CAT6A, CAT7
Telephone Cable, Alarm Cable, Coaxial Cable
As a professional manufacturer we can provide the extra savings to our customers with the best quality to help our customers grow their business and market shares.
1. All of products we offer are top quality and competitive price;
2. If there is no special explanation, all of our Brand are RISUN or OEM;
3. Payment: We accept T/T and L/C;
4. Packing:
1) Packing Lengths: 305m/roll, or other lengths available according to client's request.
2) Inner packing: Wooden reel, plastic reel, and paper reel available.
3) Outer packing: Carton box, pull box
4) Other packing available according to client's request.
5. Any question, please contact us without hesitation. We'll reply as soon as we can.
FAQ
Q1: What is the MOQ order ?
A1: MOQ is 10000meters.
If you have different and special demands, please contact with us, we'll provide the best solutions to you.
Q2: How to shipping? Is there cheap shipping cost to import to our country ?
A2:The best choice is shipping By sea. Because network cable is very heavy, it's too expensive by air.
By Sea: If you have freight forwarder, they can handle shipping for you. If you don't have it, we can provide the cheapest shipping cost to you, or send our freight forwarder information to you contact directly.
Q3. How to know recycle and new jacket materials ?
A3: Except for conductor price, the jacket materials is the main factors affecting price. Some supplier's price is crazy, because they use recycle materials in production.
Recycle material: The jacket will have bubble, especially tenacity is very bad, it's easy to tear. So the cable's lifetime is short, fire retardant & cold resistance is bad too.
New material: Tenacity is very good, it's hard to tear, and with good fire retardant & cold resistance.
Q4: Can you make OEM ?
Yes, we can supply OEM service to our international clients. It can be marking your brand or any printing that you want. Except for international famous brand.
