• Model NO.：ABC Overhead Cable
• Certification：ISO, CCC, CE, KEMA
• Model：Aeriak Bundled Cable
• Brand：Yifang
• Core：1core ~ 6core
• Colour：Black, White, Red, or as Per Requirements
• Standard：IEC 60502 Icea S 76 474 NFC 33209
• Certificate：ISO CCC CE Kema
• Transport Package：Coil, Drum
• Specification：16mm2-630mm2
• Trademark：Yifang
• Origin：Zhengzhou, Henan, China
• HS Code：8544492100
• Production Capacity：5000km Per Month

Basic Info.

Model NO. ABC Overhead Cable Certification ISO, CCC, CE, KEMA Model Aeriak Bundled Cable Brand Yifang Core 1core ~ 6core Colour Black, White, Red, or as Per Requirements Standard IEC 60502 Icea S 76 474 NFC 33209 Certificate ISO CCC CE Kema Transport Package Coil, Drum Specification 16mm2-630mm2 Trademark Yifang Origin Zhengzhou, Henan, China HS Code 8544492100 Production Capacity 5000km Per Month

Product Description

2x16mm2 Al XLPE ABC Cable (Aerial Bundled Cable)

ABC Overhead Cable (Aerial Bundled Cable) standard available such as ASTM/ICEAS, IEC, NFC, DIN, CSA, BS, and other standards required.

ABC Overhead Cable (Aerial Bundled Cable) belongs to the serious of low voltage aerial bundled cables.

1. These cables are used for electric power transmission, extensively used for rebuilding of urban and forest regions. They can improve safety and reliance of electrified wire netting.

2. Type: Two core (1 Phse core +1 Neutral Core)/Three core (2 Phse core +1 Neutral Core)/Four core (3 Phse core +1 Neutral Core)/Five core(3 Phse core +1 Neutral Core +1 Street lighting core)/Six core(3 Phse core +1 Neutral Core +2 Street lighting core)

3. Cable structure:

3.1 Two core-LV ABC CABLE
One phase core stranded around a bare or insulated neutral messenger core. Detailed as following:
3.1. 1 Rated voltage 0.6/1KV
3.1. 2 Phase Conductor: Stranded Alu conductor 1350-H19
3.1. 3 Phase Insulation: XLPE/ PVC / PE, Weather resistant
3.1. 4 Neutral messenger: AAC /AAAC /ACSR /STEEL WIRE
3.1. 5 Neutral messenger insulation(optional): XLPE/ PVC / PE, Weather resistant
3.1. 6 Core identification: Colour / Print marking / Colour stripes, others as per required

3.2 Three core-LV ABC CABLE
Two phase core stranded around a bare or insulated neutral messenger core. Detailed as following:
3.2. 1 Rated voltage 0.6/1KV
3.2. 2Phase Conductor: Stranded Alu conductor 1350-H19
3.2. 3 Phase Insulation: XLPE/ PVC / PE, Weather resistant
3.2. 4 Neutral messenger: AAC /AAAC /ACSR /STEEL WIRE
3.2. 5 Neutral messenger insulation(optional): XLPE/ PVC / PE, Weather resistant
3.2. 6 Core identification: Colour / Print marking / Colour stripes, others as per required

3.3 Four core-LV ABC CABLE
Three phase core stranded around a bare or insulated neutral messenger core. Detailed as following:
3.3.1 Rated voltage 0.6/1KV
3.3.2 Phase Conductor: Stranded Alu conductor 1350-H19
3.3. 3Phase Insulation: XLPE/ PVC / PE, Weather resistant
3.3.4Neutral messenger: AAC /AAAC /ACSR /STEEL WIRE
3.3.5 Neutral messenger insulation(optional): XLPE/ PVC / PE, Weather resistant
3.3. 6 Core identification: Colour / Print marking / Colour stripes, others as per required

3.4 Five core-LV ABC CABLE
Three phase core and one street lighting core stranded around a bare or insulated neutral messenger core. Detailed as following:
3.4. 1 Rated voltage 0.6/1KV
3.4. 2 Phase Conductor: Stranded Alu conductor 1350-H19
3.4. 3Phase Insulation: XLPE/ PVC / PE, Weather resistant
3.4. 4Neutral messenger: AAC /AAAC /ACSR /STEEL WIRE
3.4. 5 Neutral messenger insulation(optional): XLPE/ PVC / PE, Weather resistant
3.4. 6 Street lighting conductor: Stranded Alu conductor 1350-H19, 16mm2
3.4. 7 Street lighting insulation: XLPE/ PVC / PE, Weather resistant
3.4. 8 Core identification: Colour / Print marking / Colour stripes, others as per required

3.5 Six core-LV ABC CABLE
Three phase core and two street lighting core stranded around a bare or insulated neutral messenger core. Detailed as following:
3.5. 1 Rated voltage 0.6/1KV
3.5. 2 Phase Conductor: Stranded Alu conductor 1350-H19
3.5. 3Phase Insulation: XLPE/ PVC / PE, Weather resistant
3.5. 4Neutral messenger: AAC /AAAC /ACSR /STEEL WIRE
3.5. 5 Neutral messenger insulation(optional): XLPE/ PVC / PE, Weather resistant
3.5. 6 Street lighting conductor: Stranded Alu conductor 1350-H19, 16mm2
3.5. 7 Street lighting insulation: XLPE/ PVC / PE, Weather resistant
3.5. 8 Core identification: Colour / Print marking / Colour stripes, others as per required

4. Packing: Roll / Wooden drum / Iron-wooden drum

For further information, pls contact us directly.
