• Model NO.：RVV 1MM2
• Material Shape：Flat Wire
• Range of Application：Domestic and Industrial Wiring
• Certification：ISO9001, CE, UL, CCC, RoHS, VDE
• Brand：Yifang
• Rated Voltage：300,300V,300,500V,450,750V,600,1000V
• Alternative Standard：AS,NZS 5000,2:1999,BS6004
• Cores Number：Multicore
• Sectional Area：up to 800mm2
• Insulation Color：Standard
• Sheath Color：Standard
• Overview Type：Round
• Transport Package：Wooden Drum
• Specification：ISO CE SABS
• Trademark：Zhengzhou Yifang Cable Co., Ltd.
• Origin：Henan, China
• HS Code：8544492100
• Production Capacity：300km,Month

Style
Conductor
Insulation Thickness
(mm)
Jacket Thickness
(mm)
Overall Diameter
(mm)
Voltage
(V)
Sectional Area(mm2)
No./mm
H03VVH2-F
0.5*2C
16/0.2
0.5
0.6
3.4*5.5±0.15
300
0.75*2C
24/0.2
3.5*5.7±0.15
H03VV-F
0.5*2c
16/0.2
0.5
0.6
5.3±0.15
300
0.75*2c
24/0.2
5.5±0.15
0.5*3c
16/0.2
5.6±0.15
0.75*3c
24/0.2
6.0±0.15
H05VVH2-F
0.75*2C
24/0.2
0.6
0.8
4.0*6.4
500
H05VV-F
0.75*2C
24/0.2
0.6
0.8
6.5±0.15
500
0.75*3C
6.8±0.15
1.0*2C
32/0.2
6.7±0.15
1.0*3C
7±0.15
1.5*2C
48/0.2
0.7
0.9
8±0.15
1.5*3C
8.5±0.15
2.5*2C
80/0.2
0.8
1.1
9.6±0.2
2.5*3C
10±0.2

HO5VV-F electric flexible wire Description

 construction:
                     Conductor: stranded bare copper
                    Insulation: color coded PVC
                    Jacket: color coded PVC
                    Rated temperature:70ºC
                    Rated voltage: 300V/500V
                    Refer to standard VDE 0281 HD21,IEC227
Applications

For use in tool and appliance applications. Rated for continuous use from -40°C up to 70°C.

Available Certifications

    CE: 73/23/EEC, 93/68/EEC
    IEC: 60227-5, 60332.1
    VDE: 0281 Part-5
