• Model NO.：tri-rated cable
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE
• Model：H07V2-K
• Brand：No Brand
• Colour：Black, Blue, Brown, Green,Yellow, Grey, Orange
• Transport Package：in Drum or in Pallent
• Specification：1.5 2.5 4 6 10 16 25 35 50 70 95
• Trademark：OEM
• Origin：Henan
• HS Code：8544492100
• Production Capacity：10000 M Per Day

Conductor:Class 5 Flexible Plain Copper Conductor to BS EN 60228:2005 (previously BS6360)Insulation:PVC (Polyvinyl Chloride)Voltage Rating:BS6231:600/1000v, UL, CSA: 600vTemperature Rating:BS6321: 90°C (105°C for 150,000 hours) UL, CSA: 105°CInsulation Colour:Black, Red, Blue, Light Blue, Dark Blue, Yellow, Green/Yellow, Grey, Brown, Orange, White, Violet, Green, Pink.Minimum Bending Radius:6xOverall Diameter

Standards:

British Standard - BS6231 Type CK - covers single core PVC insulated electrical cables with rated voltage 600/1000V for switchgear and control gear wiring & a continuous use maximum operating temperature of 90oC. Tri-Rated cable exceeds this requirement with a maximum temperature of 105 oC in order to comply with UL758 and CSA 22.2. Tri-rated cable manufactured to BS6231 Type CK should not be confused with other cables manufactured to BS6231 Type BK which has a maximum operating temperature of 70 oC.

When installed in their target equipment, they are suitable for wiring circuits for which the prescribed alternating test voltage does not exceed 4 kV r.m.s. for 1 min. The types of cable specified in this standard are as follows:

• Type BK - For a maximum conductor operating temperature of 70°C
• Type CK - For a maximum conductor operating temperature of 90°C

Tri-rated cable exceeds these requirements with a maximum temperature of 105°C to comply with UL758 and CSA 22.2

Canadian Standards Association - CSA 22.2 - details the specific requirements for flexible cords, elevator cables and hoistway cables with a voltage rating up to a maximum of 600V.

Underwriters Laboratories - UL 758 - specifies the requirements for flexible cords, elevator cables and hoistway cables with a voltage rating up to a maximum of 600V.

Dimensions:

No.of cores x CSA	Nominal Thickness of Insulation	AWG	Nominal Weight	Nominal Overall Diameter
mm2	mm		kg/km	mm
1x0.5	0.8	22	12	2.5
1x0.75	0.8	20	15	2.7
1x1.0	0.8	18	18	2.95
1x1.5	0.8	16	23	3.2
1x2.5	0.8	14	34	3.65
1x4.0	0.8	12	48	4.2
1x6.0	0.8	10	67	4.7
1x10	1.14	8	119	6.5
1x16	1.52	6	187	8
1x25	1.52	4	291	9.4
1x35	1.52	2	406	10.6
1x50	2.02	1	580	12.9
1x70	2.02	2/0	780	14.6
1x95	2.02	3/0	1055	16.1
1x120	2.02	4/0	1175	17.9
1x150	2.41	250MCM	1425	20.2
1x185	2.41	350MCM	1735	22.85
1x240	2.41	450MCM	2310	24.4
