• Model NO.：MV Cable
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE, RoHS, UL, VDE, KEMA
• Model：MV Cable
• Brand：Yifang
• Sheath Colour：Red , Black , Other as Per Requirement
• Oil Resistant：According to Requirements
• Anti-Termite：According to Requirements
• Standard：IEC 60502
• Transport Package：Wooden Drum,Iron Wooden Drum,Steel Drum
• Specification：25-1000mm2
• Trademark：Yifang Cable
• Origin：China
• HS Code：8544601200
• Production Capacity：500km,Month

Type Name



Application

 Cu

Conductor

Al

Conductor

YJV

YJY

 YJLV

YJLV

XLPE Insulated,PVC or PE S heathed Power CableFor laying in door,tunnel,channel and underground.Unable to bear external mechanical force,but bear the traction force during laid.

YJV₂₂

YJV₂₃

 YJLV₂₂

YJLV₂₃

XLPE Insulated,Steel Tape Armoured,PVC or PE Sheathed Power Cable

For laying in tunels in door,tunnel,channel and underground.Able to bear external mechanical force,but unable to bear large pulling force.

YJV₃₂

YJV₃₃

 YJLV₃₂

YJLV₃₃

XLPE Insulated,Fine Steel Wire Armoured,PVC or PE Sheathed Power Cable

For laying in shaft with large difference of level.Able to bear external mechanical force,and moderable pulling force.

YJV₄₂

YJV₄₃

YJLV₄₂

YJLV₄₃

XLPE Insulate,Thick Steel Wire Armoured,PVC or PE Sheathed Power CableAble to bear positive pressure and pulling force





U0/Um(kv)

No.of Core

1st class

0.6/1

1.8/3

3.6/6

6/10

8.7/15

12/20

18/30

21/35

2nd class

1/1

3/3

6/6

8.7/10

12/15

18/20

-

26/35

1 Core

Section

area(mm2)

1.5-800

25-800

25-800

25-800

35-800

50-800

50-800

50-800

2 Core

Section

Area(mm2)

1.5-185

/

 /

 /

 /

 /

 /

 /

3 Core

Section

area(mm2)

1.5-400

25-400

25-400

25-400

35-400

50-400

50-400

50-400

4 Core

Section

Area(mm2)

2.5-400

25-400

 /

 /

/

/

/

/

5 Core

Section

area(mm2)

2.5-400

25-400

/

/

/

  /

/

/
