PUR-C-576 High Flexible Control Cable Shielded 300/500V 37X0.25

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Power and Control Applications
  • Conductor Material：Copper
  • Sheath Material：PUR
  • Insulation Material：PVC

Base Info

  • Model NO.：PUR-C-576 High Flexible Control Cable
  • Material Shape：Round Wire
  • Range of Application：Power and Control Applications
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemPUR-C-576 High Flexible Control CableConductorCopper wire bareInsulationPVCScreenTinned copper braidingOuter sheathPURVoltage RatingUo/U 300/500VTest Voltage3000VTemperature-5°C to +70°CColorOptionalApplicationPUR-C-576 shielded is used as a control cable for power supply chains, sensor technology, computers and for control devices of instrument and control engineering. It can be used in- and outdoors in damp and wet areas. The overall copper shield ensures exact data transmission and protects the cable against electromagnetic disturbances and influences. PUR-C-576 is suitable in areas where aggressive mineral oils occur and where strong mechanical performances are required. The PUR outer sheath is cut, notch and abrasion resistant.
