Nicr Strip/Plate

Shanghai Tankii Alloy Material Co., Ltd.
  • Type：Bare
  • Conductor Type：Solid
  • Application：Heating
  • Conductor Material：Nicrfe
  • Insulation Material：Bare
  • Melting Point：1390′c

Base Info

  • Model NO.：NiCr8020, NiCr7030, NiCr6015, NiCr3020
  • Transport Package：Spool, Coil, Wooden Case
  • Specification：0.02~8mm
  • Trademark：TANKII
  • Origin：China
  • HS Code：7223000000
  • Production Capacity：5000tons,Year

Description








Max
0.08
0.02
0.015
1.0
1.0-3.0
18.0~21.0
30.0-34.0
Bal.
-
Mechanical Properties
Max Continuous Service Temperature:
Resisivity 20ºC:
Density:
Thermal Conductivity:
Coefficient of Thermal Expansion:
Melting Point:
Elongation:
Micrographic Structure:
Magnetic Property:
1100ºC
1.04+/-0.05 ohm mm2/m
7.9 g/cm3
43.8 KJ/m·h·ºC
19×10-6/ºC (20ºC~1000ºC)
1390ºC
Min 20%
Austenite
nonmagnetic
 .
Application:
1. Used in the explosives and fireworks industry as a bridgewire in electric ignition systems.
2. Industrial and hobby hot wire foam cutters.
3. Testing the colour of the flame in the non-luminous part of fire of a cation.
4. Used in ceramics as an internal support structure.
Packaging: A full range of flexible packaging options are available to fit your individual requirements.

We professionally produce nickel-base alloy tape, include Ni80Cr20, Ni60Cr23, Ni60Cr16, Ni35Cr20, Ni20Cr25, NiMn, Ni200, Karma, Evanohm, NCHW, etc.
