Almenec Cable 34, 4mm2 NF C 34-125
YIFANG ELECTRIC GROUP INC.- Application：Construction, Overhead, Industrial, Power Station
- Voltage：High Voltage Cable
- Current：DC & AC
- Insulation Material：Bare
- Sheath Material：Bare
- Material Shape：Round Wire
Base Info
- Model NO.：AAAC
- Wire Core Material：Aluminum Alloy
- Certification：ISO, CCC, CE, RoHS
- Model：AAAC
- Brand：Yifang
- Product Name：All Aluminum Alloy Conductor AAAC ASTM BS IEC DIN
- Transport Package：Wooden Drum, Steel Drum, Wooden&Steel Drum
- Specification：6 AWG
- Trademark：YIFANG
- Origin：Zhengzhou
- HS Code：7614900000
- Production Capacity：1000 Ton,Month
Description
Yifang Electric Group Inc.Code name - 34.4 34.4 Type aluminum alloy conductor Almelec Almelec Reference Standard NF C 34-125
NF EN 50 182 NF C 34-125
NF EN 50 182 Maximum allowable continuous current AT 145 145 Cross section mm² 34.36 34.36 Outside diameter mm 7.5 7.5 Number of Single wire No.s 7 7 Diameter of Single wire mm 2.50 2.50 Net weight, ungreased kg/m 0.094 0.094 Elasticity module daN/mm² 6000 6000 Coefficient of expansion /°C 10x 23-6 10x 23-6 Calculated breaking load daN 1105 1105 Ohmic resistance in cc at 20°C Ohm/km 0.958 0.958 Length on Reel m 8600
NF EN 50 182
NF EN 50 182
