- Model NO.:MV-90
- Wire Core Material:Bare Copper Wire
- Certification:ISO, CCC
- Model:Mv-90
- Brand:Boan
- Rated Voltage:25 Kv
- Number of Cores:3
- Section:1 AWG-750 Mcm
- Class of Conductor:B
- Type of Shield:Copper Tape
- Transport Package:Heated Steel-Wooden Drum,Steel Drum
- Specification:SGS
- Trademark:DingAn
- Origin:Jiangsu Yixing, China
- HS Code:8544601200
- Production Capacity:12000 Km,Year
100% Insulation Levels (260 mil) | 133% Insulation Levels (320 mil) |
Size | Number of Strands | Conductor Nominal | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight |
Copper | Aluminum | Copper | Aluminum |
AWG of kcmil | | in | mil | in | lb/kft | mil | in | lb/kft |
1 | 19 | 0.3 | 110 | 2.33 | 2970 | 2414 | - | - | - | - |
1/0 | 19 | 0.34 | 110 | 2.41 | 3290 | 2588 | 110 | 2.73 | 3886 | 3184 |
2/0 | 19 | 0.38 | 110 | 2.5 | 3675 | 2791 | 140 | 2.88 | 4469 | 3585 |
3/0 | 19 | 0.42 | 110 | 2.65 | 4272 | 3157 | 140 | 2.98 | 5002 | 3887 |
4/0 | 19 | 0.48 | 140 | 2.83 | 5032 | 3628 | 140 | 3.10 | 5613 | 4209 |
250 | 37 | 0.52 | 140 | 2.95 | 5622 | 3961 | 140 | 3.22 | 6224 | 4563 |
300 | 37 | 0.57 | 140 | 3.06 | 6264 | 4272 | 140 | 3.33 | 6885 | 4894 |
350 | 37 | 0.62 | 140 | 3.16 | 6902 | 4576 | 140 | 3.42 | 7541 | 5216 |
400 | 37 | 0.66 | 140 | 3.25 | 7570 | 4914 | 140 | 3.52 | 8226 | 5570 |
500 | 37 | 0.74 | 140 | 3.41 | 8793 | 5472 | 140 | 3.68 | 9479 | 6158 |
600 | 61 | 0.81 | 140 | 3.6 | 10059 | 6072 | 140 | 3.94 | 10961 | 6974 |
750 | 61 | 0.91 | 140 | 3.88 | 11993 | 7016 | 140 | 4.15 | 12761 | 7784 |
