- Model NO.:MV-90
- Wire Core Material:Bare Copper Wire
- Certification:ISO, CCC
- Model:Mv-90
- Brand:Boan
- Rated Voltage:15 Kv
- Number of Cores:3
- Section:2 AWG-1000 Mcm
- Class of Conductor:B
- Type of Shield:Copper Tape
- Transport Package:Heated Steel-Wooden Drum,Steel Drum
- Specification:SGS
- Trademark:DingAn
- Origin:Jiangsu Yixing, China
- HS Code:8544601200
- Production Capacity:12000 Km,Year
100% Insulation Levels (175 mil) | 133% Insulation Levels (220 mil) |
Size | Number of Strands | Conductor Nominal | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight | Jacket Thickness | Approximate Outside Diameter | Approximate Net Weight |
Copper | Aluminum | Copper | Aluminum |
AWG of kcmil | | in | mil | in | lb/kft | mil | in | lb/kft |
2 | 7 | 0.27 | 110 | 1.89 | 2084 | 1643 | 110 | 2.09 | 2385 | 1944 |
1 | 19 | 0.3 | 110 | 1.95 | 2362 | 1807 | 110 | 2.16 | 2672 | 2116 |
1/0 | 19 | 0.34 | 110 | 2.03 | 2662 | 1961 | 110 | 2.24 | 2982 | 2281 |
2/0 | 19 | 0.38 | 110 | 2.12 | 3025 | 2142 | 110 | 2.32 | 3357 | 2473 |
3/0 | 19 | 0.42 | 110 | 2.22 | 3504 | 2389 | 110 | 2.42 | 3850 | 2735 |
4/0 | 19 | 0.48 | 110 | 2.33 | 4056 | 2652 | 110 | 2.53 | 4433 | 3021 |
250 | 37 | 0.52 | 110 | 2.45 | 4604 | 2942 | 110 | 2.70 | 5090 | 3434 |
300 | 37 | 0.57 | 110 | 2.61 | 5299 | 3307 | 110 | 2.88 | 5911 | 3910 |
350 | 37 | 0.62 | 140 | 2.77 | 6079 | 3753 | 140 | 2.98 | 6535 | 4193 |
400 | 37 | 0.66 | 140 | 2.87 | 6723 | 4067 | 140 | 3.07 | 7204 | 4528 |
500 | 37 | 0.74 | 140 | 3.03 | 7904 | 4583 | 140 | 3.24 | 8420 | 5062 |
600 | 61 | 0.81 | 140 | 3.22 | 9121 | 5134 | 140 | 3.43 | 9668 | 5641 |
750 | 61 | 0.91 | 140 | 3.43 | 10824 | 5847 | 140 | 3.63 | 11422 | 6457 |
1000 | 61 | 1.06 | 140 | 3.82 | 13907 | 7273 | 140 | 4.02 | 14584 | 7885 |
