Electric Wire H05V2-K H07V2-K H05V2-U H07V2-R PVC 90º C Insulated None Sheated Single Core Cables Copper Winding Wire
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Type：Insulated
- Conductor Type：Stranded
- Application：Overhead, Underground
- Conductor Material：Copper
- Insulation Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：H05V2-K H07V2-K H05V2-U H07V2-R
- Range of Application：Flame Retardant
- Certification：ISO9001, CE, UL, CCC, RoHS, VDE
- Brand：Feiya
- Color：Black Red Yellow, According to Voltage Level
- Whether It Is Environmentally Friendly：Yes
- Whether Quality Inspection：Provide Inspection Certificate
- Standard：Customized According to Specified National Standar
- OEM/ODM：Accepted
- Core：Single Core and Multicore
- Transport Package：Standard Export Packaging
- Specification：International General Specifications
- Trademark：Fengda
- Origin：Tianjin, China(Mainland)
- HS Code：8544492100
- Production Capacity：100000,Day
Description
Application
Heat resistant cable designed for internal wiring in switch control, relay and instrumentation panels of power switchgear and for purposes such as internal connectors in rectifier equipment, motor starters and controllers.
Standard
Construction Conductor
Flame retardant Flame retardant
EN 50525-2-31
IEC 60228,5
EN 50575:2014 + A1:2016 IEC 60332-1-2
Technical Data
Voltage Rating
H05 Uo/U 300/500
H07 Uo/U 450/750V
Minimum bending radius, fixed installation 4xOD
Construction
Conductor Class 5 flexible plain / metal coated stranded according to EN 60228.
Insulation PVC (Polyvinyl Chloride) TI3 to BS EN 50363 - 3.
| Type Code | Cross-section | Nominal Outer Diameter | Current rating, installation in open air, ambient 30°C | Total weight |
| [mm] | [mm] | [A] | [kg/km] | |
| H05V2-K | 0,5 | 2,1 | 12 | 8 |
| H05V2-K | 0,75 | 2,3 | 15 | 11 |
| H05V2-K | 1 | 2,5 | 19 | 13 |
| H07V2-K | 1,5 | 2,9 | 24 | 19 |
| H07V2-K | 2,5 | 3,6 | 32 | 30 |
| H07V2-K | 4 | 4,1 | 42 | 44 |
| H07V2-K | 6 | 4,7 | 54 | 63 |
| H07V2-K | 10 | 6,0 | 73 | 108 |
| H07V2-K | 16 | 7,0 | 98 | 160 |
| H07V2-K | 25 | 8,6 | 129 | 244 |
| H07V2-K | 35 | 9,9 | 158 | 336 |
| S07V2-K | 50 | 11,5 | 198 | 470 |
| S07V2-K | 70 | 14,0 | 245 | 670 |
| S07V2-K | 95 | 15,5 | 292 | 874 |
| Type Code | Cross-section | Nominal Outer Diameter | Current rating, installation in open air, ambient 30°C | Total weight |
| [mm] | [mm] | [A] | [kg/km] | |
| S07V2-K | 120 | 17,7 | 344 | 1092 |
| S07V2-K | 150 | 19,8 | 391 | 1368 |
| S07V2-K | 185 | 21,7 | 448 | 1680 |
| S07V2-K | 240 | 25,4 | 528 | 2220 |
