Self-Supporting Fiber Optical Drop Cable 12 Cores Butterfly Drop Cable
Hangzhou Softel Optic Co., Ltd.- Application:Fiber Optic Cable
- Conductor Material:Fiber
- Cover Material:PE
- Type:G652D
- Material Shape:Hollow Line
- Conductor Type:Stranded
Base Info
- Model NO.:GYFXBY-12B1
- Wire Core Material:Steel
- Certification:CE, ISO
- Model:Gyfxby-12b1
- Apply for:Aerial
- Fiber Count:12cores as Per Your Design
- Cable Type:Sm or mm
- Fiber Type:9,125 (G657A2)
- Material of Jacket:MDPE,HDPE
- Fiber Optic Cable Tube:Central Loose Tube
- Model Name:Fiber Optic Cable
- Model No.:GJYXFCH-8b6.A2
- Delivery Time:10 Days
- MOQ:2 Drum
- Transport Package:4km Wooden Drum
- Specification:GYFXBY-12B1
- Trademark:SOFTEL
- Origin:China
- HS Code:85176229
- Production Capacity:1000km Per Month
Description
Basic Info.
Model NO. GYFXBY-12B1 Wire Core Material Steel Certification CE, ISO Model Gyfxby-12b1 Apply for Aerial Fiber Count 12cores as Per Your Design Cable Type Sm or mm Fiber Type 9/125 (G657A2) Material of Jacket MDPE/HDPE Fiber Optic Cable Tube Central Loose Tube Model Name Fiber Optic Cable Model No. GJYXFCH-8b6.A2 Delivery Time 10 Days MOQ 2 Drum Transport Package 4km Wooden Drum Specification GYFXBY-12B1 Trademark SOFTEL Origin China HS Code 85176229 Production Capacity 1000km Per MonthProduct Description
Self-supporting fiber optical drop cable 8 cores1. Good mechanical and environmental characteristics;
2. Flame retardant characteristics meets the requirements of relevant standards;
3. The mechanical characteristics meets the requirements of relevant standards;
4. Soft, flexible, easy to splice, and with big capacity data transmission;
5. Meet various requirements of market and clients.
Characteristic:
1 Special low-bend-sensitivity fiber provides high bandwidth and excellent communication transmission property.
2 Two parallel FRP strength members ensure good performance of crush resistance to protect the fiber.
3 Single steel wire as the additional strength member ensure good performance of tensile strength.
4 Simple structure, light weight and high practicability.
5 Novel flute design, easily strip and splice, simplify the installation and maintenance.
6 Low smoke, zero halogen and flame retardant sheath.
Item | Technology parameter |
Cable type | GYFXBY-12B1 |
Fiber type | 9/125 (G652D) |
Fiber color | Blue, orange, green, brown, gray, white, red, black, yellow, violet, pink, aqua |
Filler | Jelly |
Inner jacket color | Natural |
Inner jacket material | PBT |
Inner jacket diameter mm | 3.0±0.1 |
Strength member | FRP(*2) |
Strength member diameter mm | 1.6 |
Outer sheath color | Black |
Outer sheath material | PE |
Outer sheath dimension mm | 7.7(±0.3)×4.3(±0.3) |
Cable weight Kg/km | Approx. 34.9 |
Min. bending radius mm | 20H (Static)40H (Dynamic) |
Attenuation dB/km | <= 0.4 at 1310nm, <= 0.3 at 1550nm |
Short tensile strength N | 800 |
Crush resistance N/100mm | 2200 |
Operation temperature ºC | -20~+70 |
