Low Voltage 300/500V Control Cable PVC Insulated Cu Conductor Multi Core

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Application：Fixed Installations
  • Conductor Material：Copper
  • Sheath Material：PVC
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：H05VVC4V5-K Cable
  • Range of Application：Flame Retardant
  • Certification：ISO9001, CE, UL, RoHS
  • Transport Package：Optional
  • Specification：Multi Core
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemH05VVC4V5-K PVC Control CableConductorStranded bare copper (as client's required)InsulatedPolyvinylchloride (PVC) (as client's required)Inner SheathPolyvinylchloride (PVC) (as client's required)ShieldBraiding of tinned copper wiresOuter SheathPolyvinylchloride (PVC) (as client's required)Rated Voltage300/500VTest Voltage2000VTemperature RangeIn motion: -5°C till +70°C
Fixed: -40°C till +70°CBending radiusIn motion: 15 x diameterColorOptionalApplicationSuitable for dry, damp and wet locations but not in the open-air. It is used as a screened termination and connection cable in the control, measuring and signal technology. Suitable as a signal and impulse cable for control and inspection of industrial plants, machinery and working processes.
