Super-Paar-Tronic-340-C-PUR PUR Drag Chain Cable for Outdoor Use

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：Full Polyurethane
  • Insulation Material：PP
  • Material Shape：Round Wire

Base Info

  • Model NO.：SUPER-PAAR-TRONIC-340-C-PUR
  • Range of Application：Electrical Facilities
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemSUPER-PAAR-TRONIC-340-C-PUR PUR Drag Chain CableConductorCopper wire bare, extra finely stranded, 0.5 - 1 mm²: acc. to DIN VDE 0295 Class 6 / IEC 60228 Class 6Wire structure0.14 mm²: approx. 18 x 0.1 mm0.25 mm²: approx. 32 x 0.1 mm0.34 mm²: approx. 42 x 0.1 mmInsulationPPWrippingFleeceScreenBraided screen of tinned copper wires, approx. coverage 85%Outer SheathSpecial grade of full polyurethane acc. to DIN VDE 0207-363-10-2 / DIN EN 50363-10-2 (compound type TMPU), UL-Std. 1581Nominal voltageUL (AWM) AC 300 VTest voltage core/core1500 VTest voltage core/screen1000 VTemperature RangeFlexible -30°C to +80°C
Fixed -40°C to +80°CColorOptionalCertificationCE

Properties


· Resistant to: oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids, acids, alkalis, greases, seawater and wastewater· Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion· For outdoor use· Suitable for use in drag chains· Halogen-free· The materials used during manufacturing are cadmium-free, Contain no silicone and are free from substances harmful to the wetting properties of lacquersApplicationStranded in pairs, this fully-screened special drag chain cable can also be used where external, high-frequency interference influences pulse transfer. It is used for permanently flexible stresses in machine and tool building, in robotics, on constantly moving machine components and for extended use in multi-shift operations. This two-approval cable is preferred for use in export-oriented mechanical engineering, in machine tools, production lines and systems engineering. Allows for extended use in multi-shift operations with extremely high bending stresses.
