Helukabel Alternative Jz-602 RC-C-PUR Special Cable for Drag Chains 600V

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Application：Electrical Facilities
  • Conductor Material：Copper
  • Sheath Material：Sspecial Full-Polyurethane
  • Insulation Material：PUR

Base Info

  • Model NO.：JZ-602 RC-C-PUR
  • Material Shape：Round Wire
  • Range of Application：Cold-Resistant
  • Certification：ISO9001, CE, UL, RoHS
  • Brand：Aein
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemSpecial Cable for Drag ChainsConductorBare copper, extra fine wire conductors,
to DIN VDE 0295 cl.6, BS 6360 cl.6 and
IEC 60228 cl.6InsulationSpecial PVC compound type TI2 to DIN VDE 0207-363-3/ DIN EN 50363-3
and class 43 acc. to UL-Std.1581ScreeningUp to 17 mm Ø - layer of tinned copper wires
>17 mm Ø - tinned copper wire braid coverage ca. 85%Core insulationSpecial PVC compound type TI2 to DIN VDE 0207-363-3/ DIN EN 50363-3 and class 43 acc. to UL-Std.1581Inner sheathPVCOuter SheathSpecial full-polyurethaneNominal VoltageUL/CSA 600 VTemperature RangeFlexing -5°C to +80°C
Fixed installation -40°C to +80°CColorOptionalCertificationCE/ULApplicationThese cable are used for flexible use for medium mechanical stresses with free movement without tensile stress or forced movements in dry, moist, wet rooms and outdoor. These special cables for drag chains are used for permanent flexible applications in machineries, machine tools, robot technics, for movable automated machinery parts. The dense screening assures disturbance-free transmission of all signals and impulses. An ideal disturbance-free control cable for the above applications.
