Puro-Jz-Hf-Ycp / Puro-Oz-Hf-Ycp PUR Drag Chain Cable Helukabel Alternative

Shanghai Aein Wire & Cable Co., Ltd.
  • Type：Insulated
  • Conductor Type：Stranded
  • Conductor Material：Copper
  • Sheath Material：PVC, PUR
  • Insulation Material：PVC
  • Material Shape：Round Wire

Base Info

  • Model NO.：PURo-JZ-HF-YCP , PURo-OZ-HF-YCP
  • Certification：ISO9001, CE, UL, RoHS
  • Transport Package：Optional
  • Specification：Multicore
  • Trademark：AEIN
  • Origin：Shanghai
  • HS Code：8544492100

Description

ItemPURo-JZ-HF-YCP / PURo-OZ-HF-YCP PUR Drag Chain CableConductorCopper wire bare, extra finely stranded acc. to DIN VDE 0295 Class 6 / IEC 60228 Class 6InsulationOil-resistant PVC in alignment with DIN VDE 0207- 363-3 / DIN EN 50363-3 (compound type TI2)Inner sheathPVCOuter SheathSpecial grade of full polyurethane acc. to DIN VDE 0207-363-10-2 / DIN EN 50363-10-2 (compound type TMPU)Nominal voltageAC Uo /U 300/500 VTest voltage core/core4000 VBreakdown voltage 8000 VWrappingFleece wrappingTemperature RangeFlexible -20°C to +80°C
Fixed -40°C to +80°CColorOptionalCertificationCEApplicationExtremely robust drag chain cable, which is distinguished by its high abrasion resistance and notch-tensile strength properties. Due to its resistance to mineral oils, notably against coolant emulsions, it is suited for use in particularly critical locations in machine, tool and plant construction, rolling mills and steelworks. Due to its high abrasion resistance and small bending radius, it is ideally suited for use in drag chain systems. These screened cables are ideally suited for interference-free data signal transmission in measurement and control technology.
