| Item | F-C-PURo-JZ / F-C-PURo-OZ PUR Control and Connection Cable |
| Conductor | Copper wire bare, finely stranded acc. to DIN VDE 0295 Class 5 / IEC 60228 Class 5 |
| Insulation | Oil-resistant PVC in alignment with DIN VDE 0207-363-3 / DIN EN 50363-3 (compound type TI2), with improved gliding behaviour |
| Wrapping | Foil |
| Screen | Braided screen of tinned copper wires, approx. coverage 85% |
| Outer Sheath | Special grade of full polyurethane acc. to DIN VDE 0207-363-10-2 / DIN EN 50363-10-2 (compound type TMPU) |
| Nominal voltage | AC U0/U 300/500 V |
| Test voltage core/core | 3000 V |
| Breakdown voltage | 6000 V |
| Temperature Range | Flexible -20°C to +80°C
Fixed -40°C to +80°C |
| Color | Optional |
| Certification | CE |
Properties | ·Resistant to: oil, UV radiation, ozone, oxygen, weathering effects, hydrolysis, microbes, coolants, hydraulic fluids, acids, alkalis, greases, seawater and wastewater
·Highly abrasion-resistant, notch-resistant, tear-resistant, cut-resistant, wear-resistant, low adhesion·For outdoor use·The materials used during manufacturing are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers |
| Application | Connection and control cable with a high-grade oil-resistant PVC core insulation. Due to its resistance to mineral oils, notably against coolant emulsions, it is suited for use in particularly critical locations in machine, tool and plant construction, rolling mills and steelworks. The cable can be laid quickly and easily due to its good flexibility. Suitable for flexible applications involving medium mechanical stress with free movement, without tensile stress and without forced motion control in dry, damp and wet rooms, as well as outdoors. Due to the high screening density, interference-free transmission of signals or pulses is ensured. |
