3X15 Non-Individually Screened Power Cores Three Earth Cores One Extensible Pilot Laid-up in a Semiconductive Cradle Underground Mine Cable
Tianjin Feiya Electric Wire & Cable Co., Ltd.- Application：Underground, Industrial, Power Station
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：Epr (R-Ep-90)
- Sheath Material：Heavy Duty HD-85-Pcp
- Material Shape：Round
Base Info
- Model NO.：Type 275
- Wire Core Material：Tinned Copper
- Certification：ISO, CCC, CE
- Model：Mc
- Brand：Fengda
- OEM / ODM：Available
- Rated Voltage：1.1 Kv - 11 Kv
- Installation Conditions：in Free Air, in Duct, Mobile Equipment, Machines
- Behaviour in Flame and Fire：Fire Retardant
- Transport Package：Drum
- Specification：1.8m * 1.8m * 1.1m
- Trademark：Fengda
- Origin：China
- HS Code：8544421900
- Production Capacity：50000000 Meter , Year
Description
Basic Info.
Model NO. Type 275 Wire Core Material Tinned Copper Certification ISO, CCC, CE Model Mc Brand Fengda OEM / ODM Available Rated Voltage 1.1 Kv - 11 Kv Installation Conditions in Free Air, in Duct, Mobile Equipment, Machines Behaviour in Flame and Fire Fire Retardant Transport Package Drum Specification 1.8m * 1.8m * 1.1m Trademark Fengda Origin China HS Code 8544421900 Production Capacity 50000000 Meter / YearProduct Description
UNDERGROUND MINE CABLES 1.1-11 kV
Cable description
Composite screened cable for hand-held equipment to AS/NZS 1802
Application
These cables are used with high-speed reeling equipmentemployed on shuttle cars, and are subject to the greatestexertion underground. Cable constructions are designed to
resist "corkscrewing" in these arduous conditions.
Temperature range:
Maximum operating temperature: +90 °C
Minimum operating temperature: -25 °C
Flexibility:Flexible
Resistance to
Chemical exposure: Very good/Frequent
Mechanical impact: Heavy
Water exposure: Immersion/Temporary coverage
Solar radiation and weather exposure: Suitable for direct exposure
Installation conditions
In free air / Mobile equipment
