Taifulong FEP UL1332 20AWG 200° C 300V Tinned Copper Electric Wire High Temperature Resistan Teflon Cable
Guangzhou Feng Tai Mei Hua Cable Co., Ltd.- Conductor Type:Stranded
- Application:Overhead, Heating
Base Info
- Model NO.:UL1332
- Conductor Material:Copper Plated with Tin
- Sheath Material:FEP
- Insulation Material:Teflon
- Material Shape:Round Wire
- Range of Application:Flame Retardant
- Certification:ISO9001, UL, RoHS
- Brand:Taifulong
- Rated Voltage:300V
- Rated Temperature:200′c
- Insulation:FEP
- Conductor:Copper Plated with Tin,Copper Plated with Nicke ,
- Use:Internal Wiring of Electrical and Mechanical Appli
- Specification:610Meter ,Roll
- Trademark:Taifulong
- Origin:China
- HS Code:8544110000
- Production Capacity:2000000 Meter,Day
- Package size per unit product:27.00cm * 27.00cm * 25.00cm
- Gross weight per unit product:6.000kg
Description
Overall Dia. mmInsulation Thickness (mm) Package ft/coil(m/coil) Cores No./Dia (mm) Avg. Min. 30 7/0.10 0.97 ≥0.33 ≥0.305 2000 (610) 28 7/0.12 1.04 26 7/0.16 1.17 24 7/0.20 1.29 22 19/0.15 1.45 20 19/0.19 1.65 19 19/0.21 1.75 18 19/0.235 1.88 17 19/0.26 2.01 1000 ( 305) 16 19/0.30 2.22 15 19/0.32 2.32 14 19/0.375 2.61 13 19/0.41 2.78 12 19/0.48 3.14 11 37/0.375 3.38 10 37/0.43 3.77
