• Model NO.：RG 11
• Brand：General Clad
• Center Conductor Material：Bare Copper
• Dielectric Material：Foam FEP
• Jacket Material：PVC
• Inner Shield (Braid) Coverage：60 %
• Inner Shield (Braid) Material：Aluminum
• Inner Shield (Tape) Material：Aluminum,Poly
• Outer Shield (Braid) Coverage：40 %
• Outer Shield (Braid) Material：Aluminum
• Outer Shield (Tape) Material：Aluminum,Poly, non-bonded
• Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
• Trademark：Copper clad steel wire
• Origin：China
• Production Capacity：200km,Month

Cable TypeSeries 11Center Conductor TypeSolidConstruction TypeNon-armoredJacket ColorBlackSupported ApplicationVideo
DimensionsCable Length304.8 m | 1000 ftDiameter Over Center Conductor, specific0.0641 in per 1 strandDiameter Over Dielectric7.112 mm | 0.28 inDiameter Over Inner Shield (Braid)7.899 mm | 0.311 inDiameter Over Jacket Tolerance±0.010 mmDiameter Over Jacket, nominal10.287 mm | 0.405 inDiameter Over Outer Shield (Braid)8.433 mm | 0.332 inJacket Thickness0.889 mm | 0.035 inJacket Thickness, minimum spot0.711 mm | 0.028 inCenter Conductor Gauge14 AWGInner Shield (Braid) Gauge34 AWGOuter Shield (Braid) Gauge34 AWG
Electrical SpecificationsCapacitance52.493 pF/m | 16 pF/ftCharacteristic Impedance75 ohmCharacteristic Impedance Tolerance±3 ohmConductor dc Resistance11 ohms/kft | 36.089 ohms/kmDielectric Strength, conductor to shield4000 VdcJacket Spark Test Voltage5000 VacNominal Velocity of Propagation (NVP)84 %Shield dc Resistance3.7 ohms/kft | 12.139 ohms/kmStructural Return Loss15 dB @ 1000-3000 MHz | 20 dB @ 450-1000 MHz | 22 dB @ 1-450 MHzStructural Return Loss Test Method100% Swept Tested
Material SpecificationsCenter Conductor MaterialCopper-clad steel wireDielectric MaterialFoam PEJacket MaterialPVCInner Shield (Braid) Coverage60 %Inner Shield (Braid) MaterialAluminumInner Shield (Tape) MaterialAluminum/PolyOuter Shield (Braid) Coverage40 %Outer Shield (Braid) MaterialAluminumOuter Shield (Tape) MaterialAluminum/Poly, non-bonded
Package
