• Model NO.：RG 11
• Brand：General Clad
• Center Conductor Material：Bare Copper
• Dielectric Material：Foam FEP
• Jacket Material：PVC
• Shield (Braid) Coverage：95 %
• Shield (Braid) Material：Bare Copper
• Transport Package：Packed by Carton,Wooden Drum,Wooden Pallet
• Trademark：Copper clad steel wire
• Origin：China
• Production Capacity：200km,Month

Cable TypeSeries 11Center Conductor TypeSolidConstruction TypeNon-armoredJacket ColorWhiteSupported ApplicationSecurity/CCTV
DimensionsCable Length304.8 m | 1000 ftDiameter Over Center Conductor, specific0.0641 in per 1 strandDiameter Over Dielectric7.061 mm | 0.278 inDiameter Over Inner Shield (Braid)7.595 mm | 0.299 inDiameter Over Inner Shield (Tape)7.214 mm | 0.284 inDiameter Over Jacket Tolerance±0.008 inDiameter Over Jacket, nominal9.042 mm | 0.356 inDiameter Over Outer Shield (Braid)8.204 mm | 0.323 inJacket Thickness0.432 mm | 0.017 inJacket Thickness, minimum spot0.305 mm | 0.012 inCenter Conductor Gauge14 AWGInner Shield (Braid) Gauge34 AWG
Electrical SpecificationsCapacitance52.493 pF/m | 16 pF/ftCharacteristic Impedance75 ohmCharacteristic Impedance Tolerance±3 ohmConductor dc Resistance2.9 ohms/kft | 9.514 ohms/kmDielectric Strength, conductor to shield4000 VdcJacket Spark Test Voltage5000 VacNominal Velocity of Propagation (NVP)84 %Shield dc Resistance2.5 ohms/kft | 8.202 ohms/kmStructural Return Loss20 dB @ 10-300 MHzStructural Return Loss Test Method100% Swept Tested
Material SpecificationsCenter Conductor MaterialBare copperDielectric MaterialFoam FEPJacket MaterialPVCShield (Braid) Coverage95 %Shield (Braid) MaterialBare copper
Package
