• Model NO.：Cathodic Protection Cable
• Range of Application：Cathodic Protec
• Certification：ISO9001, CE, CCC
• Brand：Yifang
• Colour：Black and Red
• Standard：ASTM D-1248
• Nos of Core：Single Core
• Rated Voltage：600V
• Transport Package：Coil, Drum, Pallet
• Specification：6mm2, 10mm2
• Trademark：Yifang cable
• Origin：Zhengzhou, Henan, China
• HS Code：8544492100
• Production Capacity：500km Per Month

TypeProduct NameCPVVCopper conductor PVC insulated and sheathed cathodic protection cable
(Cu/PVC/PVC)CPYCopper conductor HDPE insulated cathodic protection cable
(Cu/HMWPE)CPFYCopper conductor fluorine plastic insulated HDPE sheathed cathodic protection cable
(Cu/PVDM/HMWPE; Cu/KYNAR/HMWPE)CPFY33Copper conductor fluorine plastic insulated fine-steel-wire-armored HDPE sheathed cathodic protection cable
(Cu/PVDM/SWA/HMWPE; Cu/KYNAR/SWA/HMWPE)
4. Characteristics
   1) Rated voltage: DC600V
   2) Long-term permissible working temperature of cable conductor:
       PVC insulated cable: 70oC
       HMWPE insulated cable: 90oC
       PVDF/KYNAR insulated cable: 135oC
   3) The layout temperature of cable shall not be lower than -20oC
   4) The bending radius: 20D (D is outer diameter cable )
