AAAC 6201 Conductor 400sqmm 61/2.89mm
YIFANG ELECTRIC GROUP INC.- Type：Bare
- Conductor Type：Stranded
- Application：Overhead
- Conductor Material：Aluminum Alloy Conductor
- Sheath Material：None
- Insulation Material：Without
Base Info
- Model NO.：AAAC
- Material Shape：Round Wire
- Range of Application：Overhead
- Certification：ISO9001, CCC, VDE
- Brand：Yifang
- Name：All Aluminium Alloy Conductor
- Transport Package：Wooden Drum, Steel Drum, Wooden&Steel Drum
- Specification：14awg, 12awg, 8awg, 4awg, 2,0awg, 4,0awg
- Trademark：YIFANG
- Origin：Zhengzhou, Henan, China
- HS Code：8544492100
- Production Capacity：100, 000 Mt,Month
Description
AAAC-Technical characteristics / DIN 48201 Conductor size mm2 Alloy area mm2 Number of wires Diameter of wire mm Overall diameter of conductor mm Linear mass kg/km Rated tensile strength daN Maximum resistance D.C. at 20ºC Ω/km 16 15.89 7 1.70 5.10 43 444 2.0910 25 24.25 7 2.10 6.30 66 677 1.3703 35 34.36 7 2.50 7.50 94 960 0.9669 50 49.48 7 3.00 9.00 135 1382 0.6714 50 48.35 19 1.80 9.00 133 1350 0.6905 70 65.81 19 2.10 10.50 181 1838 0.5073 95 93.27 19 2.50 12.50 256 2605 0.3579 120 116.99 19 2.80 14.00 322 3268 0.2854 150 147.11 37 2.25 15.80 406 4109 0.2274 185 181.62 37 2.50 17.50 500 5073 0.1842 240 242.54 61 2.25 20.30 670 6774 0.1383 300 299.43 61 2.50 22.50 827 8363 0.1120 400 400.14 61 2.89 26.00 1104 11176 0.0838 500 499.63 61 3.23 29.10 1379 13960 0.0671 625 626.2 91 2.96 32.60 1732 17490 0.0540 800 802.09 91 3.35 36.90 2218 22402 0.0418 1000 999.71 91 3.74 41.10 2767 27922 0.0335
