• Model NO.：BC-BE4
• Wire Core Material：Bare Copper Wire
• Certification：ISO, CCC, CE, SGS
• Model：Bc -Be4
• Brand：Yifang
• Standard：IEC 60228 Class 2 & DIN 48021
• Transport Package：Wooden Drum
• Specification：10 mmsq to 185 mmsq
• Trademark：Yifang
• Origin：China
• HS Code：8544609000
• Production Capacity：3000km Per Month

Basic Info.

Model NO. BC-BE4 Wire Core Material Bare Copper Wire Certification ISO, CCC, CE, SGS Model Bc -Be4 Brand Yifang Standard IEC 60228 Class 2 & DIN 48021 Transport Package Wooden Drum Specification 10 mmsq to 185 mmsq Trademark Yifang Origin China HS Code 8544609000 Production Capacity 3000km Per Month

Product Description

1. Description
   * Plain bare soft drawn copper conductors as per IEC 60228 class 2.
   * Plain bare hard drawn Copper conductors as per DIN 48021.
2. Executive Standard
    IEC 60228 class 2 & DIN 48021.
3. Application
   * Soft drawn Copper conductors are used for electrical systems, where high conductively and
      flexibility are required.
   *  Hard drawn copper conductors are used in overhead electrical distribution networks.
4. Specifications -- Technical Information


Nominal Cross-sectional Area(mm2)	Construction Number/Diameter (mm)	Appro.overall    Diameter(mm)	Max.D.C.resistance Of      Conductor At 20ºC(Ω/km)	Appro.Weight (Kg/km)
10	7/1.35	4.05	1.788	90
16	7/1.70	5.10	1.154	143
25	7/2.10	6.30	0.7563	218
35	7/2.50	7.50	0.530	310
50	7/3.00	9.00	0.371	445
70	19/2.15	10.8	0.268	624
95	19/2.52	12.6	0.194	857
120	19/2.85	14.3	0.152	1096
150	19/3.15	15.8	0.125	1339
185	37/2.52	17.6	0.100	1673

The above data is approximate and subjected to manufacturing tolerance.

5.SERVICING

Purpose:
To establish and maintain a procedure for performing and verifying that our service meets specified requirements and that a suitable method of feedback exists from the customer back to the appropriate individual or department within YIFANG.

Scope:
YIFANG does not currently have any contracts that obligate the company to provide installation or service above and beyond normal product service and delivery.  Service activity not specified by contract (such as the treatment of a customer complaint) shall be determined and performed free of charge on a case by case basis. Service concerns will be recorded and will provide a feed-back system as required by the customer.
