onductorAnnealed or tinned copper, sizes: 0.5mm² and 0.75mm² mulitistranded(Class 5), 0.5 mm², 1.0 mm² solid(Class 1), 1.5mm² or 2.5mm², multistranded(Class 2) to BS6360InsulationXLPE (Cross Linked Polyethylene), or PE (optional)PairingTwo insulated conductors uniformly twisted together with a lay not exceeding 100mmColour codeSee technical informationIndividualAluminium/polyester tape is applied over each pair metallic side down in contactscreenwith tinned copper drain wire, 0.5mm²Binder tapePETP transparent tapeCollectiveAluminium/polyester tape is applied over the laid up pairs metallic side down inscreencontact with tinned copper drain wire, 0.5mm²Inner SheathLSOH(Low Smoke Zero Halogen) sheathAmourGalvanized steel wire armour LSOH(Low Smoke Zero Halogen) sheathOuter sheathFlame retardant to IEC60332-3-22 Halogen free to IEC60754-1 Low smoke emission to IEC61034-1-2Sheath colourBlack or blue

Parameter of Instrument cable

No.of pairsNo.and Dia. Of Wires no./mmNominal Conductor Cross-Sectional Area mm2Nominal Thick-ness of Insulation mmNominal Thick-ness of bedding mmNominal Dia. Over Bedding mmNominal Thick-ness of Armour mmNominal   Thick-ness of Sheath mmNominal Dia. Of Cable     mmApprox.       Weight         kg/km21/0.800.50.50.99.70.91.414.338051/0.800.50.51.2131.251.518.5640101/0.800.50.51.216.91.251.722.8890151/0.800.50.51.319.71.61.726.31350201/0.800.50.51.322.31.61.829.11470301/0.800.50.51.527.11.61.934.11870501/0.800.50.523522.243.43000216/0.20.50.61.111.20.91.516460516/0.20.50.61.214.51.251.620.27601016/0.20.50.61.319.31.61.826.113001516/0.20.50.61.522.61.61.829.414402016/0.20.50.61.525.71.61.932.718703016/0.20.50.61.73122.139.224005016/0.20.50.62.239.92.52.449.73930224/0.20.750.61.112.10.91.516.9500524/0.20.750.61.215.71.251.621.49201024/0.20.750.61.320.91.61.727.516101524/0.20.750.61.524.61.61.931.619602024/0.20.750.61.527.91.61.934.924203024/0.20.750.6234.422.242.831805024/0.20.750.62.243.52.52.553.5450621/1.1310.61.111.90.91.516.751551/1.1310.61.215.41.251.621.1950101/1.1310.61.320.51.61.827.31330151/1.1310.61.524.11.61.931.11680201/1.1310.61.727.72235.72540301/1.1310.6233.722.242.12900501/1.1310.62.242.52.52.552.5480027/0.531.50.61.213.61.251.619.373057/0.531.50.61.317.71.61.724.31180107/0.531.50.61.523.91.61.930.91820157/0.531.50.61.72822362350207/0.531.50.61.731.722.139.93030307/0.531.50.6238.622.548.64050507/0.531.50.62.248.922.759.35960
