0.6/1kv Cu Al Conductor Armored Power Cable
Henan Hongda Cable Co., Ltd.- Application：Construction, Underground, Industrial, Power Station
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：PVC
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：0.6,1kv Power Cable
- Certification：ISO, CCC, CE
- Model：VV
- Brand：Hongda
- Color：as Customer Requirement
- MOQ：500
- Transport Package：Steel-Wooden Drum,Wooden Drum
- Specification：As customer requirement
- Trademark：HONGDA
- Origin：China
- Production Capacity：2000m,Week
Description
Chinese Type(General Type)Designation Cu Al VV (CU/PVC/PVC) VLV (AL/PVC/PVC) Cu conductor(Al conductor)PVC insulated PVC sheathed power cable VY (CU/PVC/PE) VLY (AL/PVC/PE) Cu conductor(Al conductor)PVC insulated PE sheathed power cable VV22 (CU/PVC/STA/PVC) VLV22 (AL/PVC/STA/PVC) Cu conductor(Al conductor)PVC insulated double of steel-tape armored PVC sheathed power cable VV23 (CU/PVC/STA/PE) VLV23 (AL/PVC/STA/PE) Cu conductor(Al conductor)PVC insulated double of steel-tape armored PE sheathed power cable VV62 (CU/PVC/ATA/PVC) VLV62 (AL/PVC/STA/PVC) Cu conductor(Al conductor)PVC insulated double of aluminium-tape armored PVC sheathed power cable VV63 (CU/PVC/STA/PE) VLV63 (AL/PVC/STA/PE) Cu conductor(Al conductor)PVC insulated double of aluminium-tape armored PE sheathed power cable VV32 (CU/PVC/SWA/PVC) VLV32 (AL/PVC/SWA/PVC) Cu conductor(Al conductor)PVC insulated steel-wire armored PVC sheathed power cable VV33 (CU/PVC/SWA/PE) VLV33 (AL/PVC/SWA/PE) Cu conductor(Al conductor)PVC insulated steel-wire armored PE sheathed power cable VV72 (CU/PVC/AWA/PVC) VLV72 (AL/PVC/AWA/PVC) Cu conductor(Al conductor)PVC insulated aluminium-wire armored PVC sheathed power cable VV73 (CU/PVC/AWA/PE) VLV73 (AL/PVC/AWA/PE) Cu conductor(Al conductor)PVC insulated aluminium-wire armored PE sheathed power cable
Note: KAIQI POWER can produce "Flame-Retardant Series", "Fire-Resistant Series", "Low Smoke Halogen Free (LSHF/LSOH) Series","Low Smoke Low Halogen (LSLH) Series", etc. power cable as customer required.
Performance in line withIEC60331, IEC60332,IEC 61034,IEC60754 requirements.
5 Construction
Conductor shaped:RE=circular solid,CC=compacted circular stranded,SM=sector shaped stranded
Conductor: Plain circular ,compacted or shaped stranded copper or aluminium conductor ,conform to IEC60228 CLass 1 or Class 2
Insulation: PVC Compound Insulation
Colour identification :
1 Core: Red or Black
2 Cores: Red, Black
3 Cores: Red, Yellow, Blue
4 Cores: Red, Yellow, Blue, Black
5 Cores: Red, Yellow, Blue, Black, Green
Above 5 Cores: Black Cores with White numerals
The above identifying can be changed as order
Bedding /Inner Sheath :PVC Compound
Armour: Aluminium wire(AWA) or aluminium alloy wire(AWA), Galvanized steel wire(SWA) or steel tape(STA) ect.
Outer Sheath:PVC or PE Compound
Note: The armored material of single core cable should be non-magnetic or magnetic reduced structure. Generallly, single core armored cable (which uses steel or steel wire armored cable) only applies to DC occasions.
Note: KAIQI POWER can produce "Flame-Retardant Series", "Fire-Resistant Series", "Low Smoke Halogen Free (LSHF/LSOH) Series","Low Smoke Low Halogen (LSLH) Series", etc. power cable as customer required.
Performance in line withIEC60331, IEC60332,IEC 61034,IEC60754 requirements.
5 Construction
Conductor shaped:RE=circular solid,CC=compacted circular stranded,SM=sector shaped stranded
Conductor: Plain circular ,compacted or shaped stranded copper or aluminium conductor ,conform to IEC60228 CLass 1 or Class 2
Insulation: PVC Compound Insulation
Colour identification :
1 Core: Red or Black
2 Cores: Red, Black
3 Cores: Red, Yellow, Blue
4 Cores: Red, Yellow, Blue, Black
5 Cores: Red, Yellow, Blue, Black, Green
Above 5 Cores: Black Cores with White numerals
The above identifying can be changed as order
Bedding /Inner Sheath :PVC Compound
Armour: Aluminium wire(AWA) or aluminium alloy wire(AWA), Galvanized steel wire(SWA) or steel tape(STA) ect.
Outer Sheath:PVC or PE Compound
Note: The armored material of single core cable should be non-magnetic or magnetic reduced structure. Generallly, single core armored cable (which uses steel or steel wire armored cable) only applies to DC occasions.
