18/30 (36) Kv XLPE Insulated PVC Sheathed Unarmoured Power Cable
YIFANG ELECTRIC GROUP INC.- Application：Construction, Underground
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：18,30kv cable BM42
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：YJV
- Brand：Yifang
- Option Conductor：Aluminum
- Transport Package：Wooden or Wooden-Steel Drum
- Specification：multicores
- Trademark：Yifang Cable
- Origin：Zhengzhou, China
- HS Code：8544601200
- Production Capacity：300km,Month
Description
Conductor
Conductor Insulation Insulation Copper Sheath Overall Cable Insulation Conductor
Conductor Insulation Insulation Copper Sheath Overall Cable Insulation Conductor
Insulation Copper Inner Armour Outer Overall Cable Insulation Conductor
Insulation Copper Inner Armour Outer Overall Cable Insulation
resistance at
15.6°C (Min.)
( Mohm/km)
Size
( mm2 )
Shape
Outside
diameter
( mm )
50
70
95
120
150
C.C.
C.C.
C.C.
C.C.
C.C.
8.05
9.67
11.39
12.33
14.24
8.0
8.0
8.0
8.0
8.0
0.1
0.1
0.1
0.1
0.1
1.6
1.8
1.8
1.8
1.8
0.5
0.5
0.8
0.8
0.8
3.2
3.3
3.4
3.6
3.7
77
81
84
89
93
6900
7930
9060
11300
12500
2550
2300
2100
2000
1850
* C.C.: Stranded and compacted circular.
