2-5kv XLPE Insulated PVC Sheathed Unarmoured Power Cable 100/133% Levels
YIFANG ELECTRIC GROUP INC.- Application：Construction, Underground
- Voltage：Low and Medium Voltage Cable
- Current：DC & AC
- Insulation Material：XLPE
- Sheath Material：PVC
- Material Shape：Round Wire
Base Info
- Model NO.：5kv cable BM43
- Wire Core Material：Bare Copper Wire
- Certification：ISO, CCC, CE, RoHS, UL, VDE
- Model：YJV
- Brand：Yifang
- Option Conductor：Aluminum
- Transport Package：Wooden or Wooden-Steel Drum
- Specification：multicores
- Trademark：Yifang Cable
- Origin：Zhengzhou, China
- HS Code：8544601200
- Production Capacity：300km,Month
Description
Conductor
Insulation Sheath Overall Dia. AC Test Cable weight Conductor
approx.
Insulation Sheath Overall Dia. AC Test Cable weight
approx.
( kg / km )
Size
(AWG or MCM)
Construction
( No. / mm )
Outside Dia.
( mm )
8
6
4
2
1
7/1.23
7/1.56
7/1.96
7/2.47
19/1.69
3.70
4.67
5.88
7.42
8.43
2.29
2.29
2.29
2.29
2.29
2.03
2.03
2.03
2.03
2.03
26.4
28.5
31.1
34.4
36.7
13
13
13
13
13
864
1080
1382
1847
2176
1/0
2/0
3/0
4/0
250
C.C.
C.C.
C.C.
C.C.
C.C.
8.53
9.55
10.74
12.07
13.21
2.29
2.29
2.29
2.29
2.29
2.03
2.03
2.03
2.79
2.79
36.8
39.0
41.6
46.2
48.6
13
13
13
13
13
2480
2955
3542
4447
5101
300
350
400
C.C.
C.C.
C.C.
14.48
15.65
16.74
2.29
2.29
2.03
2.79
2.79
2.79
51.3
53.9
56.3
13
13
13
5907
6725
7545
* C.C.: Stranded and compacted circular.
